AXIS Q8642-E Outdoor PT Thermal IP Security Camera 01121-001 - 24V AC, 60 mm Lens, 30 fps

Brand:
Part Number: 01121-001
Write a Review
Replacement of: 0733-001
  • AXIS Q8642-E Outdoor PT Thermal IP Security Camera 01121-001 - 24V AC, 60 mm Lens, 30 fps
  • AXIS Q8642-E Outdoor PT Thermal IP Security Camera 01121-001 - 24V AC, 60 mm Lens, 30 fps
$9,865.77
OR
Free shipping over $300 Free Shipping
Technical Support Technical Support
3 Year Warranty 3 Year Warranty
  • Compression : MJPEG, H.264,
  • Max. FPS and Resolution : 30fps at 640 x 480
  • Lens Type : Fixed Lens
  • Lens Size : 60mm Lens
  • Sensor Type : Thermal Sensor
  • Protection Code : NEMA 4X
  • Color : White
  • Environmental : Outdoor
  • Weatherproof : Yes

Description

AXIS Q8642-E Outdoor PT Thermal IP Security Camera 01121-001

A video analytics powerhouse

AXIS Q8642-E's powerful processor lets you add the strength of the market's widest selection of video analytics solutions to your surveillance solution. For example, video analytics applications from Axis and our partners support swift and appropriate response to detected events by analyzing them, automatically dismissing non-threatening ones and instantly notifying security staff of potentially critical situations. Your staff can then view sharp, detailed footage to determine the precise nature of the threat - and act accordingly.


Swift and smooth

AXIS Q8642-E lets operators choose between really slow or super-fast pan (from 0.05 to 120 degrees per second) and tilt movement (from 0.05 to 65 degrees per second). So they get smooth and jerk-free panoramic viewing when they need it and can respond quickly to events. The camera can be column-mounted, on poles or walls for a 360° panoramic view and a ground-to-sky view from -90° to +45°. It can withstand high winds when it's in motion of up to 47-meter per second (106 mph). To accommodate any thermal PT mount model with a different lens option than AXIS Q8642-E, please see AXIS Q1942-E PT Mount.


Far + wide + sharp = accurate

AXIS Q8642-E features VGA 640x480 thermal resolution for wide-area coverage and a long range: in other words, a single camera captures events taking place in a large area and at great distance. In addition, thanks to a combination of dynamic histogram equalization, enhanced local contrast and dynamic sharpening, AXIS Q8642-E improves image contrast for sharp video with great detail in all conditions. And electronic image stabilization keeps the picture smooth even when the camera is exposed to vibrations. The result is outstanding detection capabilities and fast and easy visual verification of the nature of detected events. You can either dismiss them - or do something about them - so false alarms are kept to a minimum.


Fast and easy

AXIS Q8642-E's slim design and many available accessories let you install it anywhere you want. It has an SFP slot, so it supports cost-effective, long-distance fiber-optic connection. A 22 meter (72 feet) long, heavy-duty power cable is available as optional accessory. Designed for outdoor use, the cable has 3-wire, 12AWG and a jacket diameter of 10 mm (0.4 in).

Key features:

  • Reliable thermal detection
  • Outstanding thermal contrast - 640x480 resolution
  • Responsive positioning with quick, smooth pan and tilt capabilities
  • Save bandwidth with Zipstream
  • Smooth and steady video with electronic image stabilization

Detection Range

Focal length

Viewing angle

Detection

mm

Horizontal

Human:
1.8 x 0.5 m

Vehicle:
4 x 1.5 m

m

yards

m

yards

Detection (1.5 pixels on target)

60

10°

1833

2005

5623

6149

Recognition (6 pixels on target)

60

10°

458

501

1406

1538

Identification (12 pixels on target)

60

10°

229

251

703

769

View AllClose

Compatible products

Camera mounts - enclosures are essential to install security cameras. Each surface will require different type of mount and bracket combination. Please check with our sales team if you need help. You can call us at (866) 441-2288 or email us at sales@a1securitycameras.com with any design questions.

Additional Information

Camera Style:
Bullet
Color:
White
Compression:
MJPEG H.264
Environmental:
Outdoor
Key Features:
ONVIF Motion Detection
Lens Size:
60mm
Lens Type:
Fixed Lens
Max. FPS and Resolution:
30fps at 640 x 480
NDAA Compliant:
Protection Code:
NEMA 4X
Resolution:
VGA
SD Card Support:
Sensor Type:
Thermal Sensor
Special Technologies:
Zip Stream
Specialized Camera Feature:
Thermal
Technology:
Network (IP)
Vandal Proof:
Warranty:
3-year Manufacturer Warranty
Weatherproof:
