Hikvision DS-2TD1217-2/V1 Thermal-Optical DeepinView Turret IP Security Camera

(No reviews yet) Write a Review
Free Shipping
Frequently bought together:


Hikvision DS-2TD1217-2/V1 Thermal-Optical DeepinView Turret IP Security Camera

The Hikvision DS-2TD1217-x/V1 Thermal-Optical DeepinView Outdoor Network Turret Cameras are equipped with highly sensitive thermal and optical sensors and a graphical processing unit to run the video content analysis (VCA) algorithms developed by Hikvision’s deep learning technology.

Hikvision’s HikMicro factory manufactures the vanadium oxide uncooled focal plane array thermal sensor with best in class image quality and price. The sensor’s 160 x 120 resolution is upscaled to 320 x 240 and features adaptive AGC (Automatic Gain Control), 3D DNR (Digital Noise Reduction), and Digital Detail Enhancement for outstanding image enhancement. The 2 MP optical sensor provides outstanding color video in very dim environments down to 0.002 lux, and built-in IR illumination allows black and white optical surveillance in zero-light conditions up to 50 ft (15 m).

This camera series is an excellent solution for short-range outdoor and indoor perimeter detection, fire prevention, predictive maintenance, human smoking detection, and other applications. The total cost of ownership for this innovative camera system comes at an unprecedented low level, due to affordable installation cost and ultra-low thermal-optical camera cost, which is competitive with purely optical cameras.

Key Features:

  • 160 x 120 Resolution (Upscaled to 320 x 240)
  • Vanadium Oxide Uncooled Focal Plane Arrays
  • NETD <40 mK
  • 1.8 mm Thermal Lens
  • Adaptive AGC, 3D DNR
  • Digital Detail Enhancement
  • Smart Features:
    • Line Crossing, Intrusion, Region Entrance/Exit with Human and Vehicle Filtering
    • Temperature Exception
    • Early Warning Fire Prevention
    • Advanced Fire Detection
    • Cigarette Smoking Detection
  • Temperature Range: -4° to 302° F (-20° to 150° C)
  • Temperature Accuracy: ±14° F (±8° C)
  • 15 Pseudo Color Palettes Available
  • IP67 Protection
  • PoE (802.3af), 12 VDC, Maximum 8 W
Related Products:
  • CBM Junction Box for Dome Camera,
  • PC130T Pendant Cap for Mini Turret Camera,
  • WMS Wall mount with junction box - Short
View AllClose

Additional Information

Camera Style:
Network (IP)
NDAA Compliant:
160 x 120
