ACTi MNR-330P 16 Channel Transportation Standalone NVR Network Video Recorder
Key features of ACTi MNR-330P
- Product Type : Standalone NVR
- Maximum Resolution : Support all ACTi cameras in all resolutions
- Maximum Number of Video devices : 16
- Additional Computing Power : Yes
- Free License : 16 (16 channels for ACTi and 1 channel for third-party video device)
- Built-in PoE Connectors : 4 Ports
- Wireless : Built-in GPS, Wi-Fi (IEEE 802.11b/g/n), 4G (require optional accessories)
- Built-in Analytics : Yes
- HDD Interface : Maximum 1 2.5" SATA disk (Without Storage Disk)
- External Storage Interface : USB
- RAID Level : Software RAID 0, 1
- Digital Zoom : Yes
- e-Map : Yes
- PTZ Control : PTZ Control
- Remote Access : Workstation, Web Client, Mobile Client
- H.265, H.264, MPEG-4, MJPEG
Downloads
Datasheet
ACTi-MNR-330P-Datasheet-A1
Popular Search
Compatible products
Video recorders will require additional parts in order to perform their function. CCTV Power supply, PoE Switches, hard drives, wireless mouse, recorder mount accessories and cables are just few to be mentioned. If you have any questions to complete your security camera system, please check with our sales team first. You can call us at (866) 441-2288 or email us at sales@a1securitycameras.com with any design questions.
Additional Information
|
4K Support:
|
4K Supported
|
|
Audio Capability:
|
Two-Way Audio
|
|
Audio Input:
|
1x Channel
|
|
Audio Output:
|
1x Channel
|
|
Certifications:
|
CE
FCC
UL Listed
CCC
BSMI
E-Mark
|
|
Channel Capacity:
|
16 Channels
|
|
Compatible Integration (API):
|
ONVIF Profile S
|
|
Compliance:
|
NDAA Compliant
|
|
Compression:
|
H.264
H.265
MJPEG
MPEG4
|
|
Connection Type:
|
Wired
|
|
Dimensions:
|
264.5 x 75.1 x 133 mm (10.41 x 2.95 x 5.23 in)
|
|
Environmental:
|
Indoor
|
|
Hard Drive Ports:
|
1 SATA Port
|
|
Included Licenses:
|
16 Licenses
|
|
LED Indicator:
|
Power LED
|
|
Max. Recording Resolution:
|
8MP (4K)
|
|
Max. Storage Capacity:
|
1 TB
|
|
Mobile Apps:
|
iOS
Android
|
|
Network Interface:
|
2x RJ-45 Ports
|
|
Number of PoE Ports:
|
4 PoE Ports
|
|
Power Budget:
|
30 Watt
|
|
Power Supply:
|
12 VDC
|
|
Power for each port:
|
15.4W
|
|
Pre-Installed Storage:
|
No HDD included
|
|
Processor (CPU):
|
Intel Core i5-4300U
|
|
Product Series:
|
ACTi MNR-Series
|
|
RAM:
|
8GB
|
|
Recorder Technology:
|
Network Video Recorder (NVR)
|
|
Remote Users:
|
Unlimited
|
|
SSD Capacity:
|
64GB
|
|
Serial Interface:
|
2x RS232
|
|
Synchronous Playback:
|
16 Channel
|
|
USB Interface:
|
2x USB 2.0
1x USB 3.0
|
|
Video Output:
|
1x HDMI
1x VGA
|
|
Warranty:
|
2-year Manufacturer Warranty
|
|
Web Browser:
|
Internet Explorer
|
