Altronix AL400ULXPD16CB 16 PTC Outputs Power Supply/Charger
$229.67
- Environmental : Indoor
- Number of Supported Cameras : 16
- Output Voltage : 24VDC
- Input Current : 3.5A
- Input Voltage : 115VAC
- Output Current : 4A
Description
Altronix AL400ULXPD16CB 16 PTC Outputs Power Supply/Charger
Altronix AL400ULX series power supply/chargers convert a 115VAC, 60Hz input into a single fused, four (4), eight (8) or sixteen (16) fuse or PTC protected outputs. Outputs are selectable for 12VDC with a total of 4A max. or 24VDC with a total of 3A max.
Key Features Of Altronix AL400ULXPD16CB
-
Input
- Input 115VAC, 60Hz, 3.5A.
- Input fuse rated @ 3.5A/250V.
-
Output
- 12VDC or 24VDC selectable output.
- 12VDC @ 4A or 24VDC @ 3A supply current.
- Sixteen (16) Class 2 Rated PTC protected powerlimited outputs (auto-resettable).
- Outputs are rated @ 2.5A.
- Filtered and electronically regulated outputs.
- Short circuit and thermal overload protection.
-
Battery Backup
- Built-in charger for sealed lead acid or gel type batteries.
- Automatic switch over to stand-by battery when AC fails.
-
Supervision
- AC fail supervision (form "C" contacts).
- Notification trigger is selectable for 30 seconds (factory set) or 6 hours.
- Low battery supervision (form "C" contacts).
- Battery presence supervision (form "C" contacts).
-
Visual Indicators
- AC input and DC output LED indicators.
-
Temperature
- Operating 0° C to 49° C (32° F to 120° F).
- Storage - 20° C to 70°C ( - 4° F to 158° F).
- Relative Humidity 85% +/- 5%.
-
BTU/Hr (approx.):
- 12VDC: 25 BTU/Hr.
- 24VDC: 37 BTU/Hr.
-
- System AC input VA requirement: 402.5VA.
Downloads
Datasheet
Altronix-AL400ULXPD16CB-spec-A1.pdf
Datasheet
Altronix-AL400ULXPD16CB-inst-A1.pdf
Popular Search
Additional Information
Accessory Type:
|
Power Supply
|
Environmental:
|
Indoor
|
Input Current:
|
3.5A
|
Input Voltage:
|
115VAC
|
Number of Supported Cameras:
|
16
|
Output Current:
|
4A
|
Output Voltage:
|
24VDC
|
Warranty:
|
Life-time Warranty
|
