Description
Altronix ALTV2416X220 CCTV Power Supply - 16 Fused Outputs
ALTV2416X220 AC Wall Mount CCTV Power Supply provides 24VAC or 28VAC distributed via sixteen (16) fuse protected outputs for powering CCTV Cameras, heaters and other video accessories.
Key Features:
Input
- 220VAC, 50/60Hz, 0.5A.
Output
- Sixteen (16) fuse protected outputs.
- 24VAC @ 8A (170VA) or 28VAC @ 7A (170VA) supply current.
- Outputs are rated @ 3.5A.
- Sixteen (16) 1.56A isolated outputs.
Temperature
- Operating 0ºC to 49ºC (32ºF to 120ºF).
- Storage - 20ºC to 70ºC ( - 4ºF to 158ºF).
- Relative Humidity 85% +/- 5%.
- BTU/Hr. (approx.): 101 BTU/Hr.
- System AC input VA requirement: 110VA.
Features
- Secondary fuse rated @ 5A/250V.
- AC power LED.
- Power ON/OFF switch.
- Spare fuses provided (all models w/primary and/or secondary fuses).
- Unit maintains camera synchronization.
Downloads
Datasheet
Altronix ALTV2416X220 Datasheet
Popular Search
Additional Information
|
Accessory Type:
|
Power Supply
|
|
Color:
|
Gray
|
|
Dimensions:
|
342.9 x 330.2 x 82.55 mm (13.5 x 13 x 3.25 in)
|
|
Environmental:
|
Indoor
|
|
Input Current:
|
0.5A
|
|
Input Voltage:
|
220VAC
|
|
Mounting:
|
Wall Mount
|
|
Output Current:
|
6A
7A
|
|
Output Voltage:
|
24VAC
28VAC
|
|
Power Supply Type:
|
CCTV Power Supply
|
|
Warranty:
|
Life-time Warranty
|
