Altronix DPS1 Two Output Linear Power Supply Charger

Brand: Altronix
Part Number: DPS1
Write a Review
  • Altronix DPS1 Two Output Linear Power Supply Charger
  • Altronix DPS1 Two Output Linear Power Supply Charger
$30.95
$22.19
OR
Technical Support Technical Support
Lifetime Warranty Lifetime Warranty
  • Environmental : Indoor
  • Number of Supported Cameras : 2
  • Output Voltage : 12VDC 24VDC 6VDC
  • Output Current : 0.75A 1.2A

Description

Altronix DPS1 Two Output Linear Power Supply Charger

Altronix DPS1 power supply/charger converts a low voltage AC input into 6VDC, 12VDC or 24VDC output. This general purpose power supply has a wide range of applications for access control, security, and CCTV system accessories that require additional power.

Key Features of Altronix DPS1

  • Input
    • 6VDC or 12VDC output use TP1640 or 24VDC output use T2428100.
  • Output
    • 6VDC, 12VDC or 24VDC selectable output.
    • 1.2A continuous supply current at 6VDC-12VDC. 750mA continuous supply current at 24VDC.
    • Filtered and electronically regulated output.
    • Short circuit and thermal overload protection.
  • Battery Backup
    • Built-in charger for sealed lead acid or gel type batteries.
    • Automatic switch over to stand-by battery when AC fails.
    • Battery short circuit protection (circuit breaker).
  • Visual Indicators
    • AC input and DC output LED indicators.
  • Features
    • Extremely compact design.
    • Includes battery leads.
    • Snap Track compatible (order Altronix model number ST3).
  • Temperature
    • Operating 0ºC to 49ºC (32ºF to 120ºF).
    • Storage - 20ºC to 70ºC ( - 4ºF to 158ºF).
    • Relative Humidity 85% +/- 5%.
      • BTU/Hr. (approx.):
        • 6VDC: 4 BTU/Hr.
        • 12VDC: 7 BTU/Hr.
        • 24VDC: 9 BTU/Hr.
    • System AC input VA requirement: 6VDC: 220VA; 12VDC: 330VA; 24VDC: 960VA.

Downloads

Datasheet DS_DPS1-A1.pdf
All Security BrandsClose

Additional Information

Accessory Type:
Power Supply
Environmental:
Indoor
Number of Supported Cameras:
2
Output Current:
0.75A 1.2A
Output Voltage:
12VDC 24VDC 6VDC
Warranty:
Life-time Warranty
