Altronix eBridge100RM EoC or Long Range Ethernet Single Port Receiver, 100Mbps

Altronix eBridge100RM EoC or Long Range Ethernet Single Port Receiver - 100Mbps

eBridge100RM is a versatile dual solution Ethernet receiver/media converter which transmits data at 100Mbps full duplex and power over Coax cable or extended CAT5e cable in a PoE+ compliant format. The eBridge100RM is powered via a PoE midspan such as the Altronix NetWay series or by an endspan. The receiver passes the PoE(+) compliant power over cable to the eBridge100TM/eBridge100ST transceiver which in turn passes this power to an enabled IP Camera/device. These plug and play units facilitate cost effective solutions for IP devices that need to be installed at distances greater than 100m. They also provide a simple way to replace legacy analog products with new IP devices over existing coax or structured cable.

Key Features:

• Powered by midspan or endspan.
• PoE compliant to IEEE 802.3af (15W) and PoE+ compliant to IEEE 802.3at (30W).
• Connectivity: RJ45, auto-crossover.
• Wire type: 4-pair CAT5.
• Distance: up to 500m.
• Speed: 10/100BaseT, half/full duplex, auto negotiation.
• PoE compliant to IEEE 802.3af (15W) and PoE+ compliant to IEEE 802.3at (30W) delivered to camera by eBridge100TM. Power provided by eBridge100RM to eBridge100TM by PoE protocol.
• Throughput is rated to pass 100Mbps of data at distances up to 500m.
• Distance: Coax 300m for power delivery.
• Connectivity: BNC, RG-59/U or similar.
• Distance: CAT5e up to 500m, Coax 300m for power delivery.
• Yellow - PoE ON (by respective RJ45 jack).
• eBridge100RM and eBridge100TM:
• Yellow and Green LED (RJ45) IP Link status, 10/100Base-T/active.
• eBridge100RM: -20ºC to 49ºC ( -4ºF to 120.2ºF).
• eBridge100TM: -20ºC to 49ºC ( -4ºF to 120.2ºF).
• eBridge100ST: For 15W: -40ºC to 75ºC ( -40ºF to 167ºF); For 30W: -40ºC to 60ºC ( -40ºF to 140ºF).
• -30º to 70ºC (-22º to 158ºF).
• Relative humidity: 85%, +/- 5%, non-condensing.
• - 304.8 to 2,000m ( - 1,000 to 6,561.679ft.).
• Auto detection and protection of legacy non-PoE cameras/devices.
