Altronix LINQ2 Network Module

(No reviews yet) Write a Review
SKU:
LINQ2
UPC:
782239953233
  • Altronix LINQ2
  • Altronix LINQ2 Network Module
$94.45
Frequently bought together:

Description

Altronix LINQ2 Network Module

Altronix LINQ2 network module is designed to interface with eFlow Series, MaximalF Series, and Trove Series power supply/chargers. It enables power supply status monitoring and control of two (2) eFlow power supply/chargers over a LAN/WAN or USB connection. LINQ2 provides values on demand for AC fault status, DC current and voltage, as well as Battery fault status, and reports conditions via email and trap notifications. LINQ2 can also be used as a standalone network controlled relay powered from any 12VDC to 24VDC power supply. Two separate networked relays can be used for variety of applications, such as: reset an access control system or gate operator, CCTV camera power, trigger camera to start recording, initiate remote test sequence of security system, or trigger HVAC system.

Key Features of Altronix LINQ2

  • Input
    • Current consumption 100mA to be subtracted from the eFlow power supply's output.
    • [COM1 & COM0] ports are currently disabled, reserved for future use.
  • Outputs
    • Power output(s) can be locally or remotely controlled.
  • Features
    • Management interface for up to two (2) eFlow power supply/chargers.
    • Two (2) network controlled Form "C" relays (contact rated @ 1A./28VDC resistive load).
    • Management interface software included (USB flash drive).
    • Includes interface cables and mounting bracket.
  • Status Monitoring
    • AC status.
    • Output current draw.
    • Unit's temperature.
    • DC output voltage.
    • Low Battery/Battery presence detection.
  • Programming
    • Battery service date indication.
    • Programmable via USB or web browser.
    • Connect up to five (5) local or remote trap receivers.
  • Reporting
    • Programmable dashboard notifications.
    • E-mail notification selectable by event.
    • Event log tracks history.
  • Temperature
    • Operating temperature: 0° C to 49° C (32° F to 120.2° F).
    • Storage temperature: - 30° C to 70° C (-22° F to 158°F).
    • Relative Humidity 85% +/- 5%.
    • Operating Altitude: - 304.8 to 3,048m ( - 1000 to 10,000 ft.).
Dimensions (approximate):
  • 3.65"W x 3.25"L x 0.96"H (92.7 mm W x 82.55 mm L x 24.38 mm H).
Weights (approximate):
  • Product Weigtht: 0.4 Lbs. (0.18 kg).
  • Shipping Weigtht: 0.7 Lbs. (0.32 kg).

Downloads

User Manual altronix-LINQ2-A1.pdf
View AllClose

Additional Information

Accessory Type:
Other
Warranty:
Life-time Warranty
Input Current:
4.5A
Input Voltage:
AC 120V
Output Current:
10A
Output Voltage:
DC 24V
