Altronix PACE8PRM Long Range Ethernet 8 Port Receiver - 100Mbps per port

Altronix PACE8PRM Long Range Ethernet 8 Port Receiver - 100Mbps per port

Pace8PRM is a long range Ethernet receiver that transmits data at 100Mbps full duplex and power via CAT5e or higher cable in a PoE(+) compliant format. The Pace8PRM receiver is powered via a PoE midspan, such as the Altronix Netway series, or by an endspan. The receiver passes the PoE(+) compliant power over the cable to the Pace1PTM transceiver which in turn passes this power to an enabled IP camera/device. These plug and play units facilitate cost effective solutions for IP devices that need to be installed at the distances greater than 100m. They also provide a simple way to replace legacy analog products with new IP devices over structured cable.

Key Features:

• Input

  • Powered by midspan or endspan. PoE compliant to IEEE 802.3af (15W) and PoE+ compliant to IEEE 802.3at (30W).

• Ethernet

  • Connectivity: RJ45, auto-crossover.
  • Wire type: 4-pair CAT5e.
  • Distance: up to 500m.
  • Speed: 100BaseT, full duplex, auto negotiation. PoE compliant to IEEE 802.3af (15W) and PoE+ compliant to IEEE 802.3at (30W) delivered to camera by Pace1PTM. Power provided by Pace8PRM to Pace1PTM by PoE protocol.

• CAT5e or Higher

  • Throughput is rated to pass 100Mbps of data at distances up to 500m. With proper headend equipment this supports Megapixel, HD720, HD1080.
  • Distance: up to 500m @ 100Mbps.

• LED Indicators

  • Yellow and Green LED (by RJ45 jack):

    • IP Link status, 10/100Base-T/active.

• Temperature

  • Operating Temperature: -20ºC to 49ºC (-4ºF to 120.2ºF).
  • Storage Temperature: -30ºC to 70ºC (-22ºF to 158ºF).
  • Relative Humidity 85% +/- 5%.

• Operating Altitude

  • - 304.8 to 2,000m.
