Altronix PD16W Power Distribution Module, 16 Fused Outputs up to 28VAC/VDC, Board
$45.61
$41.44
- Output Voltage : 24VDC
- Input Current : 4.5A
- Input Voltage : 120VAC
- Output Current : 10A
Description
Altronix PD16W Power Distribution Module
Altronix PD16W UL Listed Sub-Assembly power distribution module is designed to convert a single AC or DC input into sixteen (16) individually fuse protected outputs.
Key Features:
-
Input
- 12VDC or 24VDC up to 10A.
-
Fuse Ratings
- Fuses are rated @ 3.5A/250V.
-
PTC Ratings
- PTCs are rated @ 2A/250V
-
Visual Indicators.
- Power output LED indicator (PD16W, PD16WCB).
-
Temperature
- Operating: 0° C to 49° C (32° F to 120° F).
- Storage: - 20° C to 70° C ( - 4° F to 158° F).
- Relative Humidity 85% +/- 5%.
Dimensions (approximate):
- 6"W x 5.875"L x 0.95"H (152.4 mm W x 149.225 mm L x 24.13 mm H).
Weights (approximate):
- Product Weigtht: 0.4 Lbs. (0.18 kg).
- Shipping Weigtht: 0.5 Lbs. (0.23 kg).
Popular Search
Additional Information
Accessory Type: |
Other
|
Input Current: |
4.5A
|
Input Voltage: |
120VAC
|
Output Current: |
10A
|
Output Voltage: |
24VDC
|
Warranty: |
Life-time Warranty
|
