Altronix R615DC1016CB 16 PTC Outputs CCTV Power Supply

Altronix R615DC1016CB 16 PTC Outputs CCTV Power Supply

R615DC1016CB provides 6-15VDC distributed via sixteen (16) PTC protected outputs for powering CCTV Cameras, heaters and other video accessories.

CCTV Power Supply, 16 PTC Outputs, 6-15VDC @ 10A, 115VAC, 2U

Key Features:

• Input

  • 115VAC, 50/60Hz, 1.9A.

• Output

  • Sixteen (16) PTC protected outputs (auto-resettable).
  • 6-15VDC @ 10A total output current. (0.625A per device, 2.5A max.)
  • Outputs are rated @ 2.5A.
  • Filtered and electronically regulated outputs.
  • Short circuit and thermal overload protection.

• Electrical

  • Temperature:

    • Operating: 0° C to 49° C (32° F to 120° F).
    • Storage: - 20° C to 70° C ( - 4° F to 158° F).
  • Relative Humidity 85% +/- 5%.
  • BTU/Hr (approx.): 46-77 BTU/Hr.
  • System AC input VA requirement: 218.5VA.

• Features

  • Sixteen (16) power LEDs.
  • Illuminated master power disconnect circuit breaker with manual reset.
  • 3-wire grounded line cord.
  • Removable terminal blocks with locking screw flange.
  • Spare fuses provided.
