Altronix SMP10PM24P8 Power Supply Charger - 8 Fused Outputs

(No reviews yet) Write a Review
SKU:
SMP10PM24P8
$240.45
Frequently bought together:

Description

Altronix SMP10PM24P8 Power Supply Charger - 8 Fused Outputs

SMP10PM24P8 is a multi-output power supply/charger that converts a 115VAC/60Hz input into eight (8) 24VDC outputs.

Key Features:

  • Input
    • Input 115VAC, 60Hz, 2.7A.
  • Output
    • 24VDC output.
    • 10A supply current.
    • Eight (8) fuse protected outputs.
    • Outputs are rated @ 3.5A.
    • Filtered and electronically regulated outputs.
    • Short circuit and thermal overload protection.
  • Battery Backup
    • Built-in charger for sealed lead acid or gel type batteries.
    • Zero voltage drop when switching over to battery backup.
  • Supervision
    • AC fail supervision (form "C" contacts).
    • Battery presence and low battery supervision (form "C" contacts).
  • Visual Indicators
    • AC input and DC output LED indicators.
  • Temperature
    • Operating: 0° C to 49° C (32° F to 120° F).
    • Storage: - 20° C to 70° C ( - 4° F to 158° F).
    • Relative Humidity 85% +/- 5%.
    • BTU/Hr (approx.): 122 BTU/Hr.
    • System AC input VA requirement: 310.5VA.

Downloads

View AllClose

Additional Information

Warranty:
Life-time Warranty
Accessory Type:
Power Supply
