Altronix SMP5PMCTX Single Output Supervised Power Supply/Charger

Altronix SMP5PMCTX Single Output Supervised Power Supply/Charger

SMP5PMCTX supervised power supply/charger converts a 115VAC/230VAC, 50/60Hz input into a regulated 12VDC or 24VDC output @ 4A. continuous supply current.

Key Features of Altronix SMP5PMCTX

• Input 115VAC, 50/60Hz, 0.95A or 230VAC, 50/60Hz, 0.5A
• Output:

  • 12VDC or 24VDC selectable output
  • 4A supply current
  • Filtered and electronically regulated outputs
  • Short circuit and thermal overload protection
• Battery Backup:

  • Built-in charger for sealed lead acid or gel type batteries
  • Zero voltage drop when switching over to battery backup
• Supervision:

  • 4A supply current
  • AC fail supervision (form "C" contacts)
  • Low battery supervision (form "C" contacts)
• Visual Indicators:

  • AC input and DC output LED indicators
• Temperature:

  • Operating: 0° C to 49° C (32° F to 120° F)
  • Storage: -20° C to 70° C ( -4° F to 158° F)
  • Relative Humidity 85% +/-5%
• BTU/Hr. (approx.)

  • 12VDC: 25 BTU/Hr
  • 24VDC: 49 BTU/Hr
• System AC input VA requirement:

  • 115VAC: 109.25VA
  • 230VAC: 115VA
