Altronix SMP7PM Switching Supervised Power Supply Board
✅ Help me pick a security camera
- Environmental : Indoor
- Output Voltage : 24VDC 12VDC
- Input Voltage : 28VAC
- Output Current : 6A
Description
Altronix SMP7PM Switching Supervised Power Supply Board
Altronix SMP7PM supervised power supply/charger converts a low voltage AC input into a 12VDC or 24VDC output. This unit has a wide range of applications for access control, security and CCTV system accessories that require additional power.
Key Features of Altronix SMP7PM
- Input:
- Input 28VAC.
- Output:
- 12VDC or 24VDC selectable output.
- 6A supply current.
- Filtered and electronically regulated outputs.
- Short circuit and thermal overload protection.
- Battery Backup:
- Built-in charger for sealed lead acid or gel type batteries.
- Zero voltage drop when switching over to battery backup.
- Supervision:
- AC fail supervision (form "C" contacts).
- Battery presence and low battery supervision (form "C" contacts).
- Visual Indicators:
- AC input and DC output LED indicators.
- Temperature:
- Operating: 0° C to 49° C (32° F to 120° F).
- Storage: -20° C to 70° C ( -4° F to 158° F).
- Relative Humidity 85% +/-5%.
- BTU/Hr (approx.):
- 12VDC: 37 BTU/Hr.
- 24VDC: 75 BTU/Hr.
- System AC input VA requirement: 184VA.
- 7.045"W x 4.266"L x 2.127"H
- Shipping Weight: 0.7 Lbs
- Lifetime Warranty
Popular Search
Additional Information
Accessory Type: |
Power Supply
|
Environmental: |
Indoor
|
Input Voltage: |
28VAC
|
Output Current: |
6A
|
Output Voltage: |
24VDC
12VDC
|
Warranty: |
Life-time Warranty
|
