Altronix T2428300E Open Frame Transformer - 24/28VAC @ 300VA

Altronix T2428300E Open Frame Transformer - 24/28VAC @ 300VA

Altronix T2428300E AC power supply provides power for electronic power supplies and equipment including security, access control, and surveillance devices.

Key Features:

• Input

  • 115VAC 50/60 Hz, 2.7A.
  • Fused input protection rated @ 5A/250V.

• Output

  • 24VAC @ 14A or 28VAC @ 12.5A supply current.

• Features

  • Fused input protection.
  • Green grounding lead.

• Temperature

  • Operating 0° C to 49° C ( 32° F to 120° F).
  • Storage - 20° C to 70° C ( - 4° F to 158° F).
  • Relative Humidity 85% +/- 5%.

  • BTU/Hr. (approx.):

    • 24VAC: 172 BTU/Hr.
    • 28VAC: 179 BTU/Hr.
  • System AC input VA requirement: 310.5 VA.
