Altronix T2MK77F16D Access and Power Integration

Altronix T2MK77F16D Access and Power Integration

Altronix T2MK77F16D is pre-assembled and consist of Trove2M2 enclosure with factory installed Altronix power supply/charger(s) and sub-assemblies. This kit also accommodate various combinations of Mercury boards for up to sixteen (16) doors in a single enclosure.

Key features of Altronix T2MK77F16D

• Input

  • 120VAC 60Hz/9A.

• Output

  • 24VDC up to 20A and 12VDC up to 6A max current.
  • Sixteen (16) Fail-Safe/Fail-Secure or Dry Form “C″ Outputs

• Fully assembled kit includes:

  • Trove2 enclosure with TM2 backplane
  • Two (2) eFlow104NB - Power Supply/Charger
  • Two (2) ACM8CB - PTC Access Power Controller
  • One (1) VR6 - Voltage Regulator
  • One (1) PDS8CB - Dual Input Power Distribution Module

• Dimension: 27.25"W x 21.75"L x 6.5"H (692.15 mm W x 546.1 mm L x 165.1 mm H).
