Altronix WayPoint17ADU CCTV Power Supply - Outdoor

Altronix WayPoint17ADU CCTV Power Supply - Outdoor

Altronix WayPoint17ADU Outdoor Power Supply provides 24VAC and/or 28VAC distributed via two (2) PTC protected outputs for powering CCTV Cameras, heaters, and other video accessories.

Key Features:

• Input

  • Input: 115VAC, 50/60Hz, 2.0A or 230VAC, 50/60Hz, 1.0A.

• Output

  • Output options:

    • a. 24VAC @ 7.25A max.
    • b. 28VAC @ 6.25A max.
    • c. Both 24VAC and 28VAC not to exceed 6.25A max.
  • Output PTCs rated @ 2.5A.

• Visual Indicators

  • Individual power output LED indicators.
  • Illuminated master power switch.

• Temperature

  • Operating Temperature:

    • 24VAC @ 7.25A output: - 40° C to 60° C ( - 40° F to 140° F);
    • 28VAC @ 6.25A output: - 40° C to 70° C ( - 40° F to 158° F).
  • Storage Temperature: - 40° C to 75° C (-40° F to 167° F).
  • Relative Humidity: 85% +/- 5%
  • BTU/Hr. (approx.): 90 BTU/Hr.
  • System AC input VA requirement: 230VA.

• Operating Altitude

  • - 304.8 to 2000m ( - 1000 to 6,561.679 ft.).
