Altronix WPTV248175UL 8 Fused Outputs Outdoor CCTV Power Supply - 24/28VAC @ 7A

(No reviews yet) Write a Review
SKU:
WPTV248175UL
UPC:
782239939633
  • Altronix WPTV248175UL 8 Fused Outputs Outdoor CCTV Power Supply - 24/28VAC @ 7A
  • Altronix WPTV248175UL 8 Fused Outputs Outdoor CCTV Power Supply - 24/28VAC @ 7A
$236.00
$195.13
Technical Support
  • Environmental : Outdoor
  • Number of Supported Cameras : 8
  • Output Voltage : AC 28V AC 24V
  • Input Current : 1.76A
  • Input Voltage : AC 115V
  • Output Current : 6.25A 7A

Description

Altronix WPTV248175UL 8 Fused Outputs Outdoor CCTV Power Supply - 24/28VAC @ 7A

Altronix WPTV248175UL outdoor CCTV Power Supply provides power via eight (8) fuse protected power-limited outputs for CCTV Cameras, heaters, and other video accessories.

Key features of Altronix WPTV248175UL

  • Input
    • 115VAC, 50/60Hz, 1.76A.
  • Output
    • Eight (8) fuse protected outputs.
    • 24VAC @ 7A (170VA) supply current (0.438A per device, 3.5A max.) or 28VAC @ 6.25A (175VA) supply current (0.375A per device, 3.5A max.).
    • Outputs are rated @ 3.5A.
    • Surge suppression.
  • Features
    • Secondary fuse rated @ 5A/250V.
    • AC power LED.
    • Power ON/OFF switch.
    • Spare fuses provided. (all models w/primary and/or secondary fuses).
    • NEMA 4 Rated enclosure for outdoor use.
  • Temperature
    • Operating: 0° C to 49° C (32° F to 120° F).
    • Storage: - 20° C to 70° C ( - 4° F to 158° F).
    • Relative Humidity 85% +/- 5%.
    • BTU/Hr. (approx.): 89 BTU/Hr.
    • System AC input VA requirement: 202.4VA.
View AllClose

Additional Information

Accessory Type:
Power Supply
Environmental:
Outdoor
Input Current:
1.76A
Input Voltage:
AC 115V
Number of Supported Cameras:
8
Output Current:
6.25A 7A
Output Voltage:
AC 28V AC 24V
Warranty:
Life-time Warranty
