Arecont Vision M118FM16MP Fixed-Focal Lens - 16mm

Arecont Vision M118FM16 Megapixel Fixed-Focal Industrial Lens 16mm

Arecont Vision M118FM16 Megapixel Fixed-Focal Industrial Lens 16mm supports 1/1.8", 1/2", and 1/3" image processing cameras. In addition, it is suitable for FA (Factory Automation) and Machine Vision applications, and offers a wide viewing angle of 25.9 x 19.5° for 1/1.8" megapixel cameras. The 16mm lens minimizes distortion to less than-0.7%., delivering high-quality images. The manual iris and focus loc make for correct exposures and optimum performance.

Key Features:

• Supports 1/1.8", 1/2" & 1/3" image formats
• Suitable for FA (Factory Automation) and Machine Vision applications
• 16mm focal length
• Aperture range: f/1.4-16
• Compatible with megapixel cameras
• Optimum performance in the center and at the edges
• Minimizes distortion to less than -0.7%
• Minimum focus of 0.1m
• C-type mount
• Anti-vibration construction
• 0.1m - ∞ focusing range
• Manual Iris
• M25.5 P=0.09" (0.5mm) filter size
• 0.47" back focus
• 14 - 140°F (-10 - +60°C)
• 0.086 Lbs (39g)
• Angle of view:

  o 1/1.8 format: 25.9 x 19.5°

  o 1/2 format: 22.8 x 17.1°

  o 1/3 format: 17.1 x 12.9°
