Description
AXIS F9114-R Mk II Main Unit - 02999-001
The AXIS F9114-R Mk II is a robust, AI-enabled 4-channel main unit designed for use in environments with high vibrations such as vehicles or industrial settings. It supports simultaneous connection of up to four sensor units and provides up to 4K resolution at 12/15 fps, delivering exceptional image quality. Powered by the ARTPEC-8 SoC with an integrated Deep Learning Processing Unit (DLPU), it enables advanced analytics like AXIS Object Analytics for human and vehicle classification, counting, and tracking, as well as audio and scene metadata analysis. The system also includes built-in cybersecurity measures such as Axis Edge Vault with FIPS 140-2 Level 2 certified key storage, signed video, and secure boot, ensuring high levels of data integrity and protection. Multiple encoding formats are supported including H.264, H.265, and Motion JPEG, with flexible streaming configurations. The rugged casing with FAKRA connectors allows it to withstand shock, vibration, and extreme temperatures, making it highly reliable in mission-critical deployments. Integrated I/O and serial ports, PoE support, and compatibility with Axis' full range of software platforms enhance flexibility. Extensive environmental certifications and compliance with various safety and electromagnetic standards confirm its readiness for industrial-grade use. This unit is a powerful edge-based surveillance processor built to last under demanding operational conditions.
Key Features:
- 4-channel input support; allows connection of up to four sensor units simultaneously for flexible surveillance setups.
- Up to 4K resolution at 12/15 fps; delivers high-definition image quality with advanced compression for efficient bandwidth usage.
- Built-in DLPU (deep learning processing unit); enables advanced video analytics directly at the edge without external processing.
- Supports AXIS Object Analytics; provides intelligent human and vehicle detection, tracking, and behavioral analysis.
- Rugged design with FAKRA connectors; ensures secure connections and reliable performance in high-vibration environments.
- Axis Edge Vault cybersecurity platform; includes secure boot, signed video, and encrypted key storage for hardware-level security.
- Multiple video compression formats; supports H.264, H.265, and Motion JPEG with Axis Zipstream for optimized streaming.
- Comprehensive event management; supports triggers via audio, temperature, IP changes, I/O, and metadata for flexible automation.
- Wide environmental tolerance; operates between -40 °C to 60 °C and meets IP65 and IK08 standards for weather and impact resistance.
- Versatile integration; compatible with ONVIF profiles G, M, S, and T and supports Axis Camera Application Platform (ACAP).
- Expandable storage options; includes support for encrypted microSD cards and network-attached storage for video retention.
- Built-in audio processing; includes adaptive classification of sounds such as screams and glass breaks for enhanced situational awareness.
- Secure network communication; uses protocols like HTTPS, SRTP, and 802.1X for secure data transmission and access control.
- Rich API and SDK support; allows third-party integration and customization through Axis’ VAPIX and Computer Vision SDK.
- Sustainable and compliant design; constructed with recycled materials and meets RoHS, REACH, and other global environmental standards.
