Axton
Axton AT-11E-S.11ES3810 10-degree PoE Powered Outdoor Infrared Illuminator
- SKU:
- AT-11E-S.11ES3810
Description
Axton AT-11E-S.11ES3810 10° PoE Powered Outdoor Infrared Illuminator
Just connect CAT5e cable to PoE or PoE+ midspan.
Synchronize with camera or any other system device with input or output capability, link multiple units together. Automatic On/Off, Night/Day switch via built-in photocell. Pulsed mode allows syncing with camera shutter for industrial, machine vision, and ANPR/LPR applications.
All products are covered by a lifetime warranty with advanced replacement. All Axton lights are designed and manufactured in the USA.
Key features of Axton AT-11E-S.11ES3810
- Wavelength - 850nm (IR - semi covert)
- Input Power - PoE or PoE+ (802.3af or 802.3at )
- Energy Efficient - 11 Watts
- Low Voltage
- Range: 80ft to 540ft Depending Upon Angle
- Available in Six Angles - 150˚, 90˚, 60˚x30˚, 30˚, 20˚x10˚, or 10˚
- IO Ports for Seamless Camera Sync
- Automatic Day/Night Switch
- Pulsed mode allows syncing with camera shutter.
- Rugged Construction - IP67 Rated
- Vandal Resistant
- Includes Pan/Tilt “U″ Bracket
- Simple Installation, Easy integration
- Designed and Manufactured in the USA
- Lifetime Warranty with Advanced Replacement
ANGLE | DESCRIPTION | PART NUMBER |
10˚ | 11W, MegaPixel Series, Day/Night Sensor, I/O Ports, PoE Input, 850nm, 10° | AT-11E-S.11ES3810 |
20°x10° | 11W, MegaPixel Series, Day/Night Sensor, I/O Ports, PoE Input, 850nm, 20˚ x 10° | AT-11E-S.11ES382010 |
30° | 11W, MegaPixel Series, Day/Night Sensor, I/O Ports, PoE Input, 850nm, 30° | AT-11E-S.11ES3830 |
60°x30° | 11W, MegaPixel Series, Day/Night Sensor, I/O Ports, PoE Input, 850nm, 60° x 30˚ | AT-11E-S.11ES386030 |
90˚ | 11W, MegaPixel Series, Day/Night Sensor, I/O Ports, PoE Input, 850nm, 90° | AT-11E-S.11ES3890 |
150° | 11W, MegaPixel Series, Day/Night Sensor, I/O Ports, PoE Input, 850nm, 150° | AT-11E-S.11ES38150 |
Additional Information
Accessory Type: |
Infrared Illuminators
|
Color: |
Black
|
Environmental: |
Outdoor
|
Power Consumption: |
11 Watts
|
Warranty: |
Life-time Warranty
|
Wavelength (nm): |
850
|
