Description
Axton AT-56S.56S28150 56W Smart Series IR Illuminator, 150-degree, 850nm
The Smart AT-56S IR Illuminator allows seamless and precise integration via input output (I/O) ports. Sync with a camera or any other system device with I/O capability. For easy “plug-and-play” integration, automatic DAY/NIGHT switch turns IR ON/OFF, based upon lighting conditions.
Key Features:
- Wavelength – 850nm Infrared
- Outdoor IP67 Rated
- Angle/Coverage : 10˚
- Illumination Range: up to 1,200ft. (10˚)
- Power Consumption - 56 Watts
- Input Voltage - 24-36V DC or 24V AC
- I/O Ports for Seamless Integration
- Automatic Day/Night Switch
- Rugged Construction – Vandal Resistant
- Designed and Manufactured in the USA
- Lifetime Warranty with Advanced Replacement
- Pan/Tilt U Bracket Included
| ANGLE | DESCRIPTION | PART NUMBER |
| 10˚ | 56W, Smart Series, Day/Night Sensor, I/O Ports, 24-36VDC or 24VAC Input, 850nm, 10° | AT-56S.56S2810 |
| 20°x10° | 56W, Smart Series, Day/Night Sensor, I/O Ports, 24-36VDC or 24VAC Input, 850nm, 20°x10° | AT-56S.56S282010 |
| 30° | 56W, Smart Series, Day/Night Sensor, I/O Ports, 24-36VDC or 24VAC Input, 850nm, 30° | AT-56S.56S2830 |
| 60°x30° | 56W, Smart Series, Day/Night Sensor, I/O Ports, 24-36VDC or 24VAC Input, 850nm, 60°x30° | AT-56S.56S286030 |
| 90˚ | 56W, Smart Series, Day/Night Sensor, I/O Ports, 24-36VDC or 24VAC Input, 850nm, 90° | AT-56S.56S2890 |
| 150° | 56W, Smart Series, Day/Night Sensor, I/O Ports, 24-36VDC or 24VAC Input, 850nm, 150° | AT-56S.56S28150 |
Additional Information
|
Accessory Type:
|
Infrared Illuminators
|
|
Color:
|
Black
|
|
Environmental:
|
Outdoor
|
|
Field of View (Horizontal):
|
150
|
|
Input Voltage:
|
24VDC
24VAC
36VDC
|
|
Max Power Consumption:
|
56 Watts
|
|
Night Vision Range (ft):
|
185
|
|
Warranty:
|
Life-time Warranty
|
|
Wavelength (nm):
|
850
|
