Bosch DRN-5532-414N16 32 Channel H.265 Network Video Recorder with 4TB HDD included and 16 PoE
- Compression : MJPEG, H.265, H.264,
- Pre-Installed Storage : 4 TB
- Video Output : 2x HDMI 1x VGA
- Max. Recording Resolution : 1MP 3MP 5MP 6MP 8MP (4K) 12MP (4K)
- Hard Drive Ports : 4 SATA Ports
- Max. Storage Capacity : 24 TB Storage Capacity
- Number of PoE Ports : 16 PoE Ports
Related Products

Bosch DDN-2516-212N00 16 Channel Network Video Recorder with 2TB HDD Installed
- Compression : MJPEG, H.264, H.265,
- Pre-Installed Storage : 2 TB
- Video Output : 1x VGA 1x HDMI
- Max. Recording Resolution : 8MP (4K)
- Hard Drive Ports : 2 SATA Ports
- Max. Storage Capacity : 12 TB Storage Capacity

Bosch DIP-5248GP-4HD All-in-one Recorder with 4 x 8TB Hard Drives up to 42 Channels
- Pre-Installed Storage : 32 TB
- Max. Recording Resolution : 8MP (4K)

Bosch DIP-5244GP-4HD All-in-one Recorder with 4 x 4TB Hard Drives up to 42 Channels
- Pre-Installed Storage : 16 TB
- Max. Recording Resolution : 8MP (4K)

Bosch DIP-5248IG-4HD DIVAR IP All-in-one Management Appliance - 32TB HDD included
- Pre-Installed Storage : 32 TB
- Max. Recording Resolution : 8MP (4K)

Bosch DIP-5240GP-00N DIVAR IP All-in-one Management Appliance with GPU - No HDD included
- Pre-Installed Storage : No HDD included
- Max. Recording Resolution : 8MP (4K)
Customers Also Viewed

Bosch DRN-5532-400N00 32 Channel H.265 Network Video Recorder - No HDD Included
- Compression : H.264, MJPEG, H.265,
- Pre-Installed Storage : No HDD included
- Video Output : 1x VGA 2x HDMI
- Max. Recording Resolution : 12MP (4K)
- Hard Drive Ports : 4 SATA Ports
- Max. Storage Capacity : 24 TB Storage Capacity

Bosch DRH-5532-414N00 DIVAR hybrid 5000 16 Channel Hybrid Video Recorder - 16ch IP/16ch Analog, 4TB, 1.5U
- Compression : H.265, MJPEG, H.264,
- Pre-Installed Storage : 4 TB
- Video Output : 1x VGA 2x HDMI
- Hard Drive Ports : 4 SATA Ports
- Max. Storage Capacity : 24 TB Storage Capacity
- Number of PoE Ports : 16 PoE Ports

Bosch DRH-5532-214D00 32-Channel 4TB Hybrid Network/Analog Video Recorder with DVD Burner
- Compression : MJPEG, H.265, H.264,
- Pre-Installed Storage : 4 TB
- Video Output : 2x HDMI
- Max. Recording Resolution : 12MP (4K)
- Hard Drive Ports : 2 SATA Ports
- Max. Storage Capacity : 12 TB Storage Capacity
- Number of PoE Ports : 16 PoE Ports

Bosch DRN-5532-214D00 32 Channel H.265 Network Video Recorder - 4TB, DVD
- Compression : MJPEG, H.264, H.265,
- Pre-Installed Storage : 4 TB
- Video Output : 1x VGA 2x HDMI
- Hard Drive Ports : 2 SATA Ports
- Max. Storage Capacity : 12 TB Storage Capacity

Bosch DRN-5532-400N16 32 Channel H.265 Network Video Recorder - No HDD Included, 16PoE Ports
- Compression : H.264, MJPEG, H.265,
- Pre-Installed Storage : No HDD included
- Video Output : 1x VGA 2x HDMI
- Max. Recording Resolution : 12MP (4K)
- Hard Drive Ports : 4 SATA Ports
- Max. Storage Capacity : 24 TB Storage Capacity

Bosch DRN-5532-214D16 32 Channel H.265 Network Video Recorder - 4TB, DVD, 16-PoE
- Compression : H.265, H.264, MJPEG,
- Pre-Installed Storage : 4 TB
- Video Output : 1x VGA 2x HDMI
- Hard Drive Ports : 2 SATA Ports
- Max. Storage Capacity : 12 TB Storage Capacity
- Number of PoE Ports : 16 PoE Ports

Bosch DDN-2516-212N08 16 Channel 4K H.265 NVR Network Video Recorder - 2TB Pre-installed HDD
- Compression : H.265, MJPEG, H.264,
- Pre-Installed Storage : 2 TB
- Video Output : 1x VGA 1x HDMI
- Max. Recording Resolution : 8MP (4K)
- Hard Drive Ports : 2 SATA Ports
- Max. Storage Capacity : 12 TB Storage Capacity

Bosch DRH-5532-400N00 16 Channel Analog DVR/P/DVR Hybrid Recorder - No HDD Included
- Compression : H.264, H.265,
- Pre-Installed Storage : No HDD included
- Video Output : 1x VGA 2x HDMI
- Max. Recording Resolution : 12MP (4K)
- Hard Drive Ports : 4 SATA Ports
- Max. Storage Capacity : 24 TB Storage Capacity
- Number of PoE Ports : 16 PoE Ports

8 Channel 4K Network Max. 12 TB Storage Capacity 8 PoE Ports 2 SATA Hard Drive Ports Video Recorder
- Compression : MPEG4, H.264, H.264 Plus, H.265,
- Pre-Installed Storage : No HDD included
- Video Output : 1x HDMI 1x VGA
- Max. Recording Resolution : 8MP (4K)
- Hard Drive Ports : 2 SATA Ports
- Max. Storage Capacity : 12 TB Storage Capacity
- Color : Black
- Number of PoE Ports : 8 PoE Ports

Bosch DIP-7180-00N 32 Channel Network Video Recorder - No HDD included, Up to 128ch Support
- Pre-Installed Storage : No HDD included
- Hard Drive Ports : 8 SATA Ports
- Max. Storage Capacity : 64 TB Storage Capacity

8 Megapixel (4K) 16 Channel Max. 12 TB Storage Capacity 16 PoE Ports Network Video Recorder
- Compression : MPEG4, H.265, H.264 Plus, H.264,
- Pre-Installed Storage : No HDD included
- Video Output : 1x VGA 1x HDMI
- Max. Recording Resolution : 8MP (4K)
- Hard Drive Ports : 2 SATA Ports
- Max. Storage Capacity : 12 TB Storage Capacity
- Color : Black
- Number of PoE Ports : 16 PoE Ports

Bosch DDN-2516-200N08 H.265 4K 16 Channel Network Video Recorder, No HDD included
- Compression : MJPEG, H.264, H.265,
- Pre-Installed Storage : No HDD included
- Video Output : 1x VGA 1x HDMI
- Max. Recording Resolution : 8MP (4K)
- Hard Drive Ports : 2 SATA Ports
- Max. Storage Capacity : 12 TB Storage Capacity
- Number of PoE Ports : 8 PoE Ports

LTS LTN8704Q-P4 4 Channel 4K Network Video Recorder, HDD Options available
- Compression : H.264, H.264 Plus, H.265, H.265 Plus, MPEG4,
- Pre-Installed Storage : No HDD included
- Video Output : 1x HDMI 1x VGA
- Max. Recording Resolution : 8MP (4K)
- Hard Drive Ports : 1 SATA Port
- Max. Storage Capacity : 6 TB Storage Capacity
- Environmental : Indoor

Bosch Divar IP 7000 DIP-7080-00N 32 Channel Network Video Recorder - No HDD included, 2U, All-in-one recording
- Pre-Installed Storage : No HDD included
- Hard Drive Ports : 8 SATA Ports
- Max. Storage Capacity : 16 TB Storage Capacity

LTS LTN8708Q-P8 8 Channel 4K Network Video Recorder, HDD Options Available
- Compression : H.264, H.264 Plus, H.265, H.265 Plus,
- Pre-Installed Storage : No HDD included
- Video Output : 1x HDMI 1x VGA
- Max. Recording Resolution : 8MP (4K)
- Hard Drive Ports : 1 SATA Port
- Max. Storage Capacity : 6 TB Storage Capacity

Geovision GV-SNVR0812 8-Channel 4K Network Video Recorder, No HDD Included
- Compression : H.264, H.265,
- Pre-Installed Storage : No HDD included
- Video Output : 1x HDMI 1x VGA
- Max. Recording Resolution : 8MP (4K)
- Hard Drive Ports : 1 SATA Port
- Max. Storage Capacity : 10 TB Storage Capacity
- Color : Black
- Environmental : Indoor
- Number of PoE Ports : 8 PoE Ports
- Power Budget : 100 Watt

LTS LTN8716K-HT 16 Channel 4K Hybrid Network Video Recorder
- Compression : H.265 Plus, H.265, H.264 Plus, H.264,
- Pre-Installed Storage : No HDD included
- Video Output : 1x HDMI 1x VGA
- Max. Recording Resolution : 8MP (4K)
- Hard Drive Ports : 2 SATA Ports
- Max. Storage Capacity : 16 TB Storage Capacity

Bosch DIP-3040-00N Divar IP 3000 32 Channel Network Video Recorder - No HDD included
- Pre-Installed Storage : No HDD included
- Hard Drive Ports : 4 SATA Ports
- Max. Storage Capacity : 8 TB Storage Capacity

Bosch DIP-6186-8HD DIVAR IP 6000 All-in-one Recording Management Solution with 8x6 TB HDD
- Pre-Installed Storage : 48 TB
- Hard Drive Ports : 8 SATA Ports
- Max. Storage Capacity : 64 TB Storage Capacity

Bosch DIP-6180-00N DIVAR IP 6000 All-in-one Recording Management Solution without HDD
- Pre-Installed Storage : No HDD included
- Hard Drive Ports : 8 SATA Ports
- Max. Storage Capacity : 64 TB Storage Capacity
Description
Bosch DRN-5532-414N16 32 Channel H.265 Network Video Recorder with 4TB HDD included and 16 PoE
Connect this recorder to a maximum of 32 IP cameras that use the latest H265/H264 high-resolution video technology and state-of-the-art compression techniques.
These advanced technologies, coupled with efficient network data transmission, deliver the high security and reliability required for modern surveillance systems. Simultaneous remote or local monitoring, recording, archive and playback functions are guided by simple menu selections and operator commands. The recorders can be installed with a maximum of 4 internal HDDs for video storage. Another option is two HDDs for storage, plus a DVD burner for video export. Use the recorder as a desktop model or in a standard rack mount.
The DIVAR supports H.264 video compression technology and is H.265-ready for the newest H.265 technology cameras to be released by Bosch. This technology dramatically reduces bandwidth and storage requirements while still delivering superb image and audio quality. Equipped with this newest video technology, DIVAR gives you the full benefits of the latest high-resolution cameras. The proof is in the pixels.
The recorder supports Bosch IP cameras (and 3rd party IP cameras) complying to the ONVIF Profile S specifications. The recorder only supports IP cameras with a firmware version 6.30 or higher.
The DIVAR records multiple video and audio signals while simultaneously providing live multi-screen viewing and playback. Comprehensive search and playback functions provide quick recall and viewing of recorded video. The DIVAR has a real-time display resolution of 1080p for 16 channels simultaneously, or 4K for 4 channels.
Key features:
- 32 IP channels with 320 Mbps incoming bandwidth
- 4TB HDD Installed
- 16-port PoE switch
- 1.5U Chassis
- 12 MP IP camera support for view and playback
- Real time live display for 16 channels @1080p or
- 4 channels @4k
- Extended rack-mount unit with advanced connections
- Separate internet and IP camera networks
Downloads
Popular Search
Additional Information
Alternative SKUs: |
F.01U.329.385
|
Channel Capacity: |
32 camera channels
|
Compression: |
MJPEG
H.265
H.264
|
Hard Drive Ports: |
4 SATA Ports
|
Max. Incoming Bandwidth: |
320Mbps
|
Max. Recording Resolution: |
1MP
3MP
5MP
6MP
8MP (4K)
12MP (4K)
|
Max. Storage Capacity: |
24 TB
|
NDAA Compliance: |
NDAA Compliant
|
Number of PoE Ports: |
16 PoE Ports
|
Outgoing Bandwidth: |
320 Mbps
|
Pre-Installed Storage: |
4 TB
|
Rack Unit (U): |
1.5U
|
Recorder Technology: |
Network Video Recorder (NVR)
|
Video Output: |
2x HDMI
1x VGA
|
Warranty: |
3-year Manufacturer Warranty
|
e-SATA: |
YES
|
Related Products

Bosch DDN-2516-212N00 16 Channel Network Video Recorder with 2TB HDD Installed
- Compression : MJPEG, H.264, H.265,
- Pre-Installed Storage : 2 TB
- Video Output : 1x VGA 1x HDMI
- Max. Recording Resolution : 8MP (4K)
- Hard Drive Ports : 2 SATA Ports
- Max. Storage Capacity : 12 TB Storage Capacity

Bosch DIP-5248GP-4HD All-in-one Recorder with 4 x 8TB Hard Drives up to 42 Channels
- Pre-Installed Storage : 32 TB
- Max. Recording Resolution : 8MP (4K)

Bosch DIP-5244GP-4HD All-in-one Recorder with 4 x 4TB Hard Drives up to 42 Channels
- Pre-Installed Storage : 16 TB
- Max. Recording Resolution : 8MP (4K)

Bosch DIP-5248IG-4HD DIVAR IP All-in-one Management Appliance - 32TB HDD included
- Pre-Installed Storage : 32 TB
- Max. Recording Resolution : 8MP (4K)

Bosch DIP-5240GP-00N DIVAR IP All-in-one Management Appliance with GPU - No HDD included
- Pre-Installed Storage : No HDD included
- Max. Recording Resolution : 8MP (4K)
Customers Also Viewed

Bosch DRN-5532-400N00 32 Channel H.265 Network Video Recorder - No HDD Included
- Compression : H.264, MJPEG, H.265,
- Pre-Installed Storage : No HDD included
- Video Output : 1x VGA 2x HDMI
- Max. Recording Resolution : 12MP (4K)
- Hard Drive Ports : 4 SATA Ports
- Max. Storage Capacity : 24 TB Storage Capacity

Bosch DRH-5532-414N00 DIVAR hybrid 5000 16 Channel Hybrid Video Recorder - 16ch IP/16ch Analog, 4TB, 1.5U
- Compression : H.265, MJPEG, H.264,
- Pre-Installed Storage : 4 TB
- Video Output : 1x VGA 2x HDMI
- Hard Drive Ports : 4 SATA Ports
- Max. Storage Capacity : 24 TB Storage Capacity
- Number of PoE Ports : 16 PoE Ports

Bosch DRH-5532-214D00 32-Channel 4TB Hybrid Network/Analog Video Recorder with DVD Burner
- Compression : MJPEG, H.265, H.264,
- Pre-Installed Storage : 4 TB
- Video Output : 2x HDMI
- Max. Recording Resolution : 12MP (4K)
- Hard Drive Ports : 2 SATA Ports
- Max. Storage Capacity : 12 TB Storage Capacity
- Number of PoE Ports : 16 PoE Ports

Bosch DRN-5532-214D00 32 Channel H.265 Network Video Recorder - 4TB, DVD
- Compression : MJPEG, H.264, H.265,
- Pre-Installed Storage : 4 TB
- Video Output : 1x VGA 2x HDMI
- Hard Drive Ports : 2 SATA Ports
- Max. Storage Capacity : 12 TB Storage Capacity

Bosch DRN-5532-400N16 32 Channel H.265 Network Video Recorder - No HDD Included, 16PoE Ports
- Compression : H.264, MJPEG, H.265,
- Pre-Installed Storage : No HDD included
- Video Output : 1x VGA 2x HDMI
- Max. Recording Resolution : 12MP (4K)
- Hard Drive Ports : 4 SATA Ports
- Max. Storage Capacity : 24 TB Storage Capacity

Bosch DRN-5532-214D16 32 Channel H.265 Network Video Recorder - 4TB, DVD, 16-PoE
- Compression : H.265, H.264, MJPEG,
- Pre-Installed Storage : 4 TB
- Video Output : 1x VGA 2x HDMI
- Hard Drive Ports : 2 SATA Ports
- Max. Storage Capacity : 12 TB Storage Capacity
- Number of PoE Ports : 16 PoE Ports

Bosch DDN-2516-212N08 16 Channel 4K H.265 NVR Network Video Recorder - 2TB Pre-installed HDD
- Compression : H.265, MJPEG, H.264,
- Pre-Installed Storage : 2 TB
- Video Output : 1x VGA 1x HDMI
- Max. Recording Resolution : 8MP (4K)
- Hard Drive Ports : 2 SATA Ports
- Max. Storage Capacity : 12 TB Storage Capacity

Bosch DRH-5532-400N00 16 Channel Analog DVR/P/DVR Hybrid Recorder - No HDD Included
- Compression : H.264, H.265,
- Pre-Installed Storage : No HDD included
- Video Output : 1x VGA 2x HDMI
- Max. Recording Resolution : 12MP (4K)
- Hard Drive Ports : 4 SATA Ports
- Max. Storage Capacity : 24 TB Storage Capacity
- Number of PoE Ports : 16 PoE Ports

8 Channel 4K Network Max. 12 TB Storage Capacity 8 PoE Ports 2 SATA Hard Drive Ports Video Recorder
- Compression : MPEG4, H.264, H.264 Plus, H.265,
- Pre-Installed Storage : No HDD included
- Video Output : 1x HDMI 1x VGA
- Max. Recording Resolution : 8MP (4K)
- Hard Drive Ports : 2 SATA Ports
- Max. Storage Capacity : 12 TB Storage Capacity
- Color : Black
- Number of PoE Ports : 8 PoE Ports

Bosch DIP-7180-00N 32 Channel Network Video Recorder - No HDD included, Up to 128ch Support
- Pre-Installed Storage : No HDD included
- Hard Drive Ports : 8 SATA Ports
- Max. Storage Capacity : 64 TB Storage Capacity

8 Megapixel (4K) 16 Channel Max. 12 TB Storage Capacity 16 PoE Ports Network Video Recorder
- Compression : MPEG4, H.265, H.264 Plus, H.264,
- Pre-Installed Storage : No HDD included
- Video Output : 1x VGA 1x HDMI
- Max. Recording Resolution : 8MP (4K)
- Hard Drive Ports : 2 SATA Ports
- Max. Storage Capacity : 12 TB Storage Capacity
- Color : Black
- Number of PoE Ports : 16 PoE Ports

Bosch DDN-2516-200N08 H.265 4K 16 Channel Network Video Recorder, No HDD included
- Compression : MJPEG, H.264, H.265,
- Pre-Installed Storage : No HDD included
- Video Output : 1x VGA 1x HDMI
- Max. Recording Resolution : 8MP (4K)
- Hard Drive Ports : 2 SATA Ports
- Max. Storage Capacity : 12 TB Storage Capacity
- Number of PoE Ports : 8 PoE Ports

LTS LTN8704Q-P4 4 Channel 4K Network Video Recorder, HDD Options available
- Compression : H.264, H.264 Plus, H.265, H.265 Plus, MPEG4,
- Pre-Installed Storage : No HDD included
- Video Output : 1x HDMI 1x VGA
- Max. Recording Resolution : 8MP (4K)
- Hard Drive Ports : 1 SATA Port
- Max. Storage Capacity : 6 TB Storage Capacity
- Environmental : Indoor

Bosch Divar IP 7000 DIP-7080-00N 32 Channel Network Video Recorder - No HDD included, 2U, All-in-one recording
- Pre-Installed Storage : No HDD included
- Hard Drive Ports : 8 SATA Ports
- Max. Storage Capacity : 16 TB Storage Capacity

LTS LTN8708Q-P8 8 Channel 4K Network Video Recorder, HDD Options Available
- Compression : H.264, H.264 Plus, H.265, H.265 Plus,
- Pre-Installed Storage : No HDD included
- Video Output : 1x HDMI 1x VGA
- Max. Recording Resolution : 8MP (4K)
- Hard Drive Ports : 1 SATA Port
- Max. Storage Capacity : 6 TB Storage Capacity

Geovision GV-SNVR0812 8-Channel 4K Network Video Recorder, No HDD Included
- Compression : H.264, H.265,
- Pre-Installed Storage : No HDD included
- Video Output : 1x HDMI 1x VGA
- Max. Recording Resolution : 8MP (4K)
- Hard Drive Ports : 1 SATA Port
- Max. Storage Capacity : 10 TB Storage Capacity
- Color : Black
- Environmental : Indoor
- Number of PoE Ports : 8 PoE Ports
- Power Budget : 100 Watt

LTS LTN8716K-HT 16 Channel 4K Hybrid Network Video Recorder
- Compression : H.265 Plus, H.265, H.264 Plus, H.264,
- Pre-Installed Storage : No HDD included
- Video Output : 1x HDMI 1x VGA
- Max. Recording Resolution : 8MP (4K)
- Hard Drive Ports : 2 SATA Ports
- Max. Storage Capacity : 16 TB Storage Capacity

Bosch DIP-3040-00N Divar IP 3000 32 Channel Network Video Recorder - No HDD included
- Pre-Installed Storage : No HDD included
- Hard Drive Ports : 4 SATA Ports
- Max. Storage Capacity : 8 TB Storage Capacity

Bosch DIP-6186-8HD DIVAR IP 6000 All-in-one Recording Management Solution with 8x6 TB HDD
- Pre-Installed Storage : 48 TB
- Hard Drive Ports : 8 SATA Ports
- Max. Storage Capacity : 64 TB Storage Capacity

Bosch DIP-6180-00N DIVAR IP 6000 All-in-one Recording Management Solution without HDD
- Pre-Installed Storage : No HDD included
- Hard Drive Ports : 8 SATA Ports
- Max. Storage Capacity : 64 TB Storage Capacity
