Bosch DS720I Long Range Tritech PIR Motion Detector - 10.525GHz, 90ft x 70ft Coverage, Motion Monitor
Description
Bosch DS720I Long Range Tritech PIR Motion Detector
Bosch DS720I Long Range TriTech PIR Detector covers up to 91m and provides seamless safety and security. This detector features motion monitor and anti-masking protection. The field replaceable mirrored optics and three different coverage patterns provide installation flexibility.
Key features:
- Form C reed relay rated at 3.0 W, 125 mA at 28 VDC for resistive loads
- 4.7 , 0.5 W resistor in the common C leg
- Ceiling mount or 4" octagonal electrical box
- 32 mA nominal at 12VDC; up to 60 mA during walk test, stored alarm, or trouble conditions
- 9 VDC to 15 VDC Voltage
- 4.6 m (15ft) maximum height
- No alarm or setup on frequencies in the range 26MHz-950MHz at 50 V/m.
- -20°F to +120°F(-29°C to +49°C) operating temperature
- High impact ABS plastic enclosure
- Dimensions: 8" x 7.5" x 5"
Parts included:
- B334 Swivel Mount Bracket
- Standard Broad Coverage Mirror, labelled OA90
- Long Range Coverage Mirror, labelled OA300
Downloads
Popular Search
Additional Information
Accessory Type: |
Motion Detector
|
Alternative SKUs: |
4.998.800.006
|
Frequency: |
10.525 GHz
|
NDAA Compliance: |
NDAA Compliant
|
Warranty: |
3-year Manufacturer Warranty
|
