Description

Bosch PLE-1MA060-US Plena 60 Watt Commercial Mixer Amplifier

Bosch's Plena Easy Line mixer amplifiers are professional public address units with modern state of the art features. They are easy to use, taking the complexity away from the user and putting it where it belongs, inside the equipment. Providing a crisp call or clear music is as easy as turning on the radio. The Plena Easy Line offers the essentials of public address in an affordable package.

Key features of Bosch PLE-1MA060-US

  • Output power: 70V/8 Ohm - 60W RMS, 90W max
  • Frequency response: 50 Hz to 20 kHz (+1/-3 dB @ -10 dB ref. rated output)
  • Distortion: <1% @ rated output power, 1 kHz
  • Input 1 (push-to-talk contact with ducking): 5-pin Euro style, balanced, phantom; or, 3-pin XLR, balanced, phantom
  • Inputs 2-4 (VOX with ducking on input 2): 3-pin XLR, balanced, phantom
  • Sensitivity: 1mV (mic); 1V (line)
  • Impedance: >1k Ohm (mic); >5k Ohm (line)
  • Dynamic range: 93 dB
  • S/N (flat at max volume): >63 dB (mic); >70 dB (line)
  • S/N (flat at min volume/muted): >75 dB
  • Speech filter: -3 dB @ 315 Hz, high-pass, 6 dB/oct
  • Phantom power supply: 16V via 1.2k Ohm (mic)
