Description
Dahua DHI-ASR1102A(V2) Fingerprint RFID Reader
Key Features:
- RS-485 protocol
- Default IC (Mifare) card ("-D" means ID EM card)
- Support card, fingerprint
- Up to 3000 fingerprints capacity
- Blue backlight
- Watch dog function ensure device free from halting
- Beep and indicator
- Surface mounted installation
Downloads
Datasheet
Dahua-DHI-ASR1102A(V2)-Datasheet-A1
Popular Search
Specifications
|
Technical Specification |
||
|
Mode |
ASR1102A(V2) |
ASR1102A-D(V2) |
|
System |
||
|
Main Processor |
8 Bit |
|
|
Read |
||
|
Read Format |
13.56MHz |
125KHz |
|
Read Range |
1cm–9cm (max.) |
|
|
Reading time |
<0.1s |
|
|
Fingerprint |
||
|
Capacity |
3000 |
|
|
Response Time |
≤1.5s |
|
|
FAR |
≤0.00004% |
|
|
FRR |
≤0.15% |
|
|
Function |
||
|
Tamper Alarm |
Yes |
|
|
Interface |
||
|
To Controller |
RS485 |
|
|
General |
||
|
LCD Display |
Blue backlight |
|
|
Beep Tone |
Buzzer |
|
|
Power Supply |
9V–15V DC/200mA |
|
|
Operating Temperature |
-10°C to +55°C |
|
|
Working Humidity |
5%–95% |
|
|
Dimension(W×D×H) |
125mm×56mm×47mm |
|
|
Weight |
0.25kg |
|
|
Working Environment |
Indoor |
|
|
Certificates |
||
|
CE |
Yes |
|
|
FCC |
Yes |
|
