Description
Dahua DHI-HCVR78A16S-24TB 16 Channel Tribrid 1080P-Pro 16-Channel Tribrid 2U HDCVI DVR (24TB HDD)
| Model | DHI-HCVR78A16S | |
| System | ||
| Main Processor | Embedded processor | |
| Operating System | Embedded LINUX | |
| Video | ||
| Input | 16 channel | |
| Video Standard | HDCVI | 1080P/720P HDCVI Camera |
| Analog | NTSC | |
| IP | All channels support 1080P/720P IP Camera | |
| Audio | ||
| Input | 16 channel, BNC | |
| Output | 1 channel, BNC | |
| Two-way Talk | 1 channel input,1channel output, BNC | |
| Display | ||
| Interface | 2 HDMI, 1 VGA, 1 TV | |
| Resolution | 1920x1080, 1280x1024, 1280x720, 1024x768 | |
| Display Split | 1/4/8/9/16 | |
| Privacy Masking | 4 rectangular zones (each camera) | |
| OSD | Camera title, Time, Video loss, Camera lock, Motion detection, Recording | |
| Recording | ||
| Video/Audio Compression | H.264/G.711 | |
| Record Rate |
Main stream | 1080P/720P/960H/D1/HD1/2CIF/CIF(1~30fps) |
| Extra stream | CIF/QCIF(1~30fps) | |
| Bit Rate | 48~6144Kb/s | |
| Recording Mode | Manual, Schedule(Regular(Continuous), MD, Alarm), Stop | |
| Recording Interval | 1~60 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec | |
| Video Detection & Alarm | ||
| Trigger Events | Recording, PTZ, Tour, Alarm out, Video Push, Email, FTP, Snapshot, Buzzer & Screen tips | |
| Motion Detection | Motion Detection, MD Zones: 396(22x18), Video Loss & Camera Blank | |
| Alarm Input | 16 channel | |
| Relay Output | 6 channel | |
| Playback & Backup | ||
| Sync Playback | 1/4/9/16 | |
| Search Mode | Time/Date, Alarm, MD & Exact search (accurate to second), Smart search | |
| Playback Functions | Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom | |
| Backup Mode | USB Device/eSATA Device/Internal SATA burner/Network | |
| Network | ||
| Ethernet | 2RJ-45 port (10/100M/1000M) | |
| Network Functions | HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, Alarm Server, SNMP, P2P | |
| Max. User Access | 128 users | |
| Smart Phone | iPhone, iPad, Android, Windows Phone | |
| Storage | ||
| Internal HDD | 8 SATA ports(8HDDs or 6HDDs+1CD/DVD-RW), up to 32TB | |
| External HDD | 1 eSATA port | |
| Auxiliary Interface | ||
| USB | 4 ports(2 Rear), USB2.0 | |
| RS232 | 1 port, For PC communication & Keyboard | |
| RS485 | 1 port RS485 for PTZ control | |
| General | ||
| Power Supply | AC 100~240 V, 50/60 Hz | |
| Power Consumption | 40W(without HDD) | |
| Working Environment | -10℃~+55℃/10%~90%RH/86~106kpa | |
| Dimension(WxDxH) | 2U, 440mmx460mmx89mm | |
| Weight | 6.5KG(without HDD) | |
Key features of Dahua DHI-HCVR78A16S-24TB
- Support HDCVI/Analog/IP Video input
- H264 dual-stream video compression
- All channel 1080P realtime recording
- HDMI/VGA simultaneous video output
- 4/8 Ch synchronous realtime playback & GRID interface
- Support 8 SATA HDD up to 32TB, 1 eSATA, 4 USB2.0
- 3D Intelligent Positioning with Dahua PTZ Camera
Downloads
Firmware
Dahua-DHI-HCVR78A16S-Firmware-A1
Popular Search
Additional Information
|
Channel Capacity:
|
4 Channels
|
|
Hard Drive Ports:
|
1 SATA Port
|
|
Pre-Installed Storage:
|
24 TB
|
|
Recorder Technology:
|
Digital Video Recorder (DVR)
|
