Dahua N42B3P 16-Channel H.265 4K Network Video Recorder

(No reviews yet) Write a Review
Maximum Purchase:
1000 units
  • Dahua N42B3P 16-Channel H.265 4K Network Video Recorder
  • Dahua N42B3P 16-Channel H.265 4K Network Video Recorder
  • Dahua N42B3P 16-Channel H.265 4K Network Video Recorder
  • Dahua N42B3P 16-Channel H.265 4K Network Video Recorder
Frequently bought together:


Dahua N42B3P 16-Channel H.265 4K Network Video Recorder

Dahua's Lite Series network video recorders offer excellent performance and high recording quality for IP video surveillance applications. For applications where details are critical for identification, this professional NVR provides a powerful processor with up to 4K resolution. Additionally, the NVR features a mouse shortcut operation menu, remote management and control, center storage, edge storage, and back up storage.

Designed as a cost-effective and easy to install recorder, this NVR is an ideal addition to any security system that monitors public spaces, water conservancy, transportation, city centers, schools, and financial institutions.

The NVR is compatible with numerous third-party devices making it the perfect solution for surveillance systems with or without a video management system (VMS). Its open architecture supports multi-user access and it is compatible with ONVIF 2.4, enabling interoperability when combined with 4K cameras.

Key features:

  • 16-Channel
  • HDD Options available
  • H.265 and H.264 Video Compression
  • Maximum 200 Mbps Incoming Bandwidth
  • Up to 8 MP Resolution for Preview and Playback
  • Simultaneous HDMI and VGA Video Output
  • Support for IPC and UPnP Protocols
  • 16 PoE Ports
  • Support for Automatic Network Replenishment (ANR) Technology
4K Resolution

4K resolution is a revolutionary breakthrough in image processing technology. 4K delivers four times the resolution of Full HD 1080p devices and offers superior picture quality and image details. 4K resolution improves the clarity of a magnified scene to view or record crisp forensic video from large areas.

Smart Motion Detection

Smart Motion Detection, a component of Dahua's Analytics+ technology, improves alarm accuracy and decreases the number of false alarms. The advanced SMD algorithm analyzes a scene for human or vehicle motion, while filtering out other motion due to trees, leaves, animals, weather, and triggers an alarm when detected¹.

Intelligent Video System (IVS) Recording

Working with IVS-enabled IP cameras, the NVR recognizes and records video that contains IVS data on all IP channels. The NVR records standard intelligence at-the-edge features, as well as premium IVS features that detect abandoned or missing objects, Tripwire violations, and intrusion violations. The NVR is also capable of recording business analysis data – Facial Detection, People Counting, and Heat Map – from IP cameras with built-in Intelligent Business Analytics.

Heat Map

The Heat Map option highlights the areas with the highest concentration of people. This information can then be exported into a customized report to assist in business or forensic analysis.

Automatic Network Replenishment (ANR) Technology

Network Video Recorders with the ANR function automatically store video data on an IP camera SD card when the network is disconnected. After recovery of the network, the NVR automatically retrieves the video data stored on the camera.

Smart Add

The Smart Add function makes installing an IP surveillance system quick and easy. The NVR automatically detects and lists IP cameras connected to the same router as the NVR. This automatic detection makes adding cameras to the NVR a seamless process.

View AllClose

Additional Information

Product Type:
Hard Drive Ports:
2 SATA Ports
Recorder Channel Capacity:
16 camera channels
Number of PoE Ports:
16 PoE Ports
Max. Incoming Bandwidth:
Max. Storage Capacity:
12 TB
Rack Unit (U):
5-year Manufacturer Warranty
Video Output:
Video Output:
1x VGA
Recorder Technology:
Network Video Recorder (NVR)
4K Support:
ePoE Technology:
User Guide:
