Dahua X74A3L 32 Channel 4K 16+16CH 1.5U Penta-brid Digital Video Recorder

Brand: Dahua
Part Number: X74A3L2
Write a Review
  • Dahua X74A3L 32 Channel 4K 16+16CH 1.5U Penta-brid Digital Video Recorder
  • Dahua X74A3L 32 Channel 4K 16+16CH 1.5U Penta-brid Digital Video Recorder
  • Dahua X74A3L 32 Channel 4K 16+16CH 1.5U Penta-brid Digital Video Recorder
  • Dahua X74A3L 32 Channel 4K 16+16CH 1.5U Penta-brid Digital Video Recorder
Free shipping over $300 Free Shipping
Technical Support Technical Support
5 Year Warranty 5 Year Warranty
  • Compression : H.264 Plus, H.265 Plus,
  • Max. Recording Resolution : 12MP (4K)


Dahua X74A3L 32 Channel 4K 16+16CH 1.5U Penta-brid Digital Video Recorder

The X74A Series HDCVI DVR offers 4K recording on each HDCVI channel and a host of advanced features and functions. The X74A takes advantage of HDCVI technology for easy integration into existing video surveillance systems while leveraging existing networks, cabling, and cameras. Penta-brid access technology seamlessly records video from HDCVI, AHD, TVI, CVBS, and IP sources simultaneously on each channel. The X74A utilizes the Smart H.265+ Codec to significantly improve encoding efficiency and to reduce bandwidth and storage costs. In addition to the advanced codec, the X74A series supports fisheye dewarping and Point of Sale (PoS) integration. This recorder is the ideal solution for actively monitoring and recording video feeds in a wide range of applications including public venues, retail stores, transportation hubs and access ways, personal property and homes, and educational institutions.

Key features:

  • 4K at 7 fps Recording Resolution on All HDCVI Channels
  • Dual-stream Video Recording
  • Smart H.265+ and Smart H.264+ Dual Codec
  • Auto-detection of HD Analog Video Inputs
  • 16 + 16 IP Camera Channels, each channel up to 12 MP
  • Maximum 128 Mbps Incoming Bandwidth
  • Intelligent Video System with Facial Detection
  • Advanced Voice Compression Codec G.711 and PCM
  • Spot Output
  • Five-year Warranty (for products sold through an authorized Dahua dealer)
Smart H.265+

Smart H.265+ is the optimized implementation of the H.265 codec that uses a scene-adaptive encoding strategy, dynamic GOP, dynamic ROI, flexible multi-frame reference structure and intelligent noise reduction to deliver high-quality video without straining the network. Smart H.265+ technology reduces bit rate and storage requirements by up to 90% when compared to the H.264 video compression standard.

4K Resolution

The HDCVI DVR records 4K resolution on each HDCVI and IP channel. 4K is a revolutionary breakthrough in image processing technology. 4K delivers four times the resolution of standard HDTV 1080p cameras and offers superior picture quality and image details. 4K resolution improves the clarity of a magnified scene to view or record crisp forensic video from large areas.

Coaxial Audio

The HDCVI DVR accepts and records audio signals from HDCVI cameras with a built-in microphone via the Video IN BNC connection, reducing the number of connections and easing installation. The HDCVI DVR offers volume control for live audio directly from the on-screen menu.


The HDCVI DVR automatically recognizes the incoming signals of each attached camera without any setup, making installation easy and operation convenient.

Spot Output

The HDCVI DVR provides a spot output channel for a secondary monitor. This monitor allows the operator to view one monitor that is assigned to selected cameras or video inputs from high-security areas.

Point of Sale (POS)

Ideal for grocery and retail stores, the optional POS solution allows the HDCVI DVR to receive a POS transaction via corresponding video. This feature allows merchants to analyze specific transactions via the Fuzzy Search Algorithm.

Smart Fan Design

The HDCVI DVR automatically turns on or turns off the fan according to the CPU temperature. This function reduces fan noise and helps to conserve electricity.

Intelligent Video System (IVS)

IVS is a built-in video analytic algorithm that delivers standard intelligent functions to monitor a scene for Tripwire violations, intrusion detection, and abandoned or missing objects. IVS quickly and accurately responds to monitoring events in a specific area.

Face Detection

This technology identifies human faces in digital images and then searches a database to identify the individual in the image.

Smart Search

Smart Search allows an operator to specify a region in the playback video to search for a motion detection event, saving time and manpower.

Additional Information

4K Support:
4K Supported
Channel Capacity:
32 camera channels
H.264 Plus H.265 Plus
Max. Incoming Bandwidth:
Max. Recording Resolution:
12MP (4K)
NDAA Compliance:
Rack Unit (U):
Recorder Technology:
Digital Video Recorder (DVR)
5-year Manufacturer Warranty
ePoE Technology:
