Dahua X82R2A 8 Channel 4K Penta-brid HD-CVI Digital Video Recorder - HDD Options available

Brand: Dahua
Part Number: X82R2A2
Write a Review
  • Dahua X82R2A 8 Channel 4K Penta-brid HD-CVI Digital Video Recorder - HDD Options available
  • Dahua X82R2A 8 Channel 4K Penta-brid HD-CVI Digital Video Recorder - HDD Options available
  • Dahua X82R2A 8 Channel 4K Penta-brid HD-CVI Digital Video Recorder - HDD Options available
  • Dahua X82R2A 8 Channel 4K Penta-brid HD-CVI Digital Video Recorder - HDD Options available
  • Dahua X82R2A 8 Channel 4K Penta-brid HD-CVI Digital Video Recorder - HDD Options available
  • Dahua X82R2A 8 Channel 4K Penta-brid HD-CVI Digital Video Recorder - HDD Options available
$547.18
OR
Free shipping over $300 Free Shipping
Technical Support Technical Support
5 Year Warranty 5 Year Warranty
  • Compression : Smart H.265 Plus, H.265, Smart H.264 Plus, H.264,
  • Video Output : 1x HDMI 1x VGA
  • Hard Drive Ports : 2 SATA Ports
  • Max. Storage Capacity : 16 TB Storage Capacity
  • Dimensions : 375.0 x 321.0 x 53.80 (14.76 x 12.64 x 2.14 in)
  • Number of PoE Ports : 16 PoE Ports

Description

Dahua X82R2A 8 Channel 4K Penta-brid HD-CVI Digital Video Recorder

The X82R Series HDCVI DVR offers 4K recording on each HDCVI channel and a host of advanced features and functions. The X82R takes advantage of HDCVI technology for easy integration into existing video surveillance systems while leveraging existing networks, cabling, and cameras. Penta-brid access technology seamlessly records video from HDCVI, AHD, TVI, CVBS, and IP sources simultaneously, plus the DVR delivers 4K resolution on each HDCVI or IP channel. This recorder is the ideal solution for actively monitoring public venues, retail stores, transportation hubs and access ways, personal property and homes, and educational institutions.

Key Features:

  • 4K at 15 fps Recording Resolution on All HDCVI Channels
  • Available with a 2 TB, 4 TB, 6 TB, or 8 TB Pre-installed Hard Drive
  • Dual-stream Video Recording
  • AI Coding Technology for High-quality Human/Vehicle Video
  • Auto-detection and Auto-configuration of Video Inputs
  • 8 + 8 IP Camera Channels, each channel up to 8 MP
  • Maximum 128 Mbps Incoming Bandwidth
  • Perimeter Protection and Smart Motion Detection (SMD)
  • Long-distance Video Transmission
  • Five-year Warranty (for ;products sold through an authorized Dahua Dealer)
WizSense

WizSense Series devices combine Dahua's powerful Analytics+ with an intuitive and easy to use interface. WizSense devices offer Smart Motion Detection and Perimeter Protection functions that focus on human and vehicular images and ignore irrelevant images to capture important video while reducing false alarms. WizSense Series devices provide powerful general surveillance for small to medium size businesses at a sensible price.

Perimeter Protection

Dahua Analytics+ includes Tripwire and Intrusion functions that offer custom tripwires based on object type for automation in limited access areas. Perimeter Protection requires less pixels to detect an object to deliver improved accuracy and decreased false alarms due to lights, weather, trees, or animals.

Smart Motion Detection

The Smart Motion Detection, a component of Dahua's Analytics+ technology, improves alarm accuracy and decreases the number of false alarms. The advanced SMD algorithm analyzes a scene for human or vehicle motion, while filtering out other motion due to trees, leaves, animals, weather, and triggers an alarm when detected.

AI Coding

The AI Coding function puts recording emphasis on human or vehicular objects in the video scene. This technology, based on constant bit rate (CBR), dynamically allocates increased bit rate to the target object while reducing the bit rate allocated to background objects. AI Coding reduces bit rate and storage requirements by up to 50% when compared to the H.265 video compression standard.

Smart H.265+

Smart H.265+ is the optimized implementation of the H.265 codec that uses a scene-adaptive encoding strategy, dynamic GOP, dynamic ROI, flexible multi-frame reference structure and intelligent noise reduction to deliver high-quality video without straining the network. Smart H.265+ technology reduces bit rate and storage requirements by up to 90% when compared to the H.264 video compression standard.

4K Resolution

The HDCVI DVR records 4K resolution on each HDCVI and IP channel. 4K is a revolutionary breakthrough in image processing technology. 4K delivers four times the resolution of standard HDTV 1080p cameras and offers superior picture quality and image details. 4K resolution improves the clarity of a magnified scene to view or record crisp forensic video from large areas.

HDCVI/AHD/TVI/CVBS Auto-detect

The HDCVI DVR automatically recognizes the incoming signals of each attached camera without any setup, making installation easy and operation convenient.

Long Distance Transmission

HDCVI technology guarantees real-time transmission over long distances without loss of video quality. HDCVI devices provide the same resolution as most IP network camera systems using existing RG-59, RG-6, or CAT 6 UTP cabling.

All Security BrandsClose

Compatible products

Video recorders will require additional parts in order to perform their function. CCTV Power supply, PoE Switches, hard drives, wireless mouse, recorder mount accessories and cables are just few to be mentioned. If you have any questions to complete your security camera system, please check with our sales team first. You can call us at (866) 441-2288 or email us at sales@a1securitycameras.com with any design questions.

Additional Information

4K Support:
4K Supported
Alarm Input:
4 Channel
Audio Input:
1x RCA
Audio Output:
1x RCA
Channel Capacity:
8 camera channels
Compatible Integration (API):
SDK ONVIF Profile S CGI Conformant
Compression:
Smart H.265 Plus H.265 Smart H.264 Plus H.264
Dimensions:
375.0 x 321.0 x 53.80 (14.76 x 12.64 x 2.14 in)
Hard Drive Ports:
2 SATA Ports
Max. Incoming Bandwidth:
200Mbps
Max. Storage Capacity:
16 TB
Mobile Apps:
iOS Android
NDAA Compliance:
Network Interface:
1x RJ-45 10M/100M/1000M self-adaptive Ethernet Interface
Number of PoE Ports:
16 PoE Ports
Operating System:
Embedded LINUX
Operating Temperature:
-10 °C to 55 °C (14 °F to 131 °F)
Processor (CPU):
Multi-core Embedded Processor
Rack Unit (U):
1U
Recorder Technology:
Digital Video Recorder (DVR)
Relay Output:
2 Channels
Remote Users:
Up to 128
Serial Interface:
1x RS232
Special Recorder Features:
WizSense
Storage Humidity:
0% to 90% RH
Storage Temperature:
-20 °C to 70 °C (-4 °F to 158 °F)
Synchronous Playback:
1 Channel 4 Channel 9 Channel 16 Channel
USB Interface:
2x USB 2.0
Video Output:
1x HDMI 1x VGA
Warranty:
5-year Manufacturer Warranty
ePoE Technology:
