Digital Watchdog DW-BJP1U30T 64 Channel Network Video Recorder with 30TB HDD included, 4 IP licenses included
- Pre-Installed Storage : 30 TB
Description
Digital Watchdog DW-BJP1U30T 64 Channel Network Video Recorder
Blackjack P-Rack servers can record and manage single- and multi-sensor IP cameras of any resolution, with an equivalent capacity of up to 64 2.1MP cameras at 30fps and a maximum of 360Mbps throughput. Standard features include Intel i5, Windows 10 IoT or Linux Ubuntu OS and 2x NIC cards. Blackjack P-Rack™ servers can be configured with 30TB HDD and come with our 5 year limited warranty.
Key Features:
- Supports All ONVIF conformant IP cameras
- Storage options 30TB internal storage
- Record and manage single- and multi-sensor IP cameras of any resolution up to 64 2.1MP cameras at 30fps and a maximum of 360Mbps throughput
- True HD, VGA and DVI local monitoring outputs ports
- Dual network ports
- Windows® 10 IoT or Linux® Ubuntu® 16.04 OS on separate SSD
- USB interface
- Hosting DW Spectrum® IPVMS for setup, configuration, monitoring and recording
- One-time recording license charge, fully transferable between cameras and encoders
- One (1) DW Spectrum® IPVMS 4-channel licenses included (DW-SPECTRUMLSC004)
- No annual maintenance fees
- Simple enterprise scalability
- Auto device discovery
- Dual stream recording
- Rail kit Included
- USB mouse and keyboard included
- Designed, assembled and tested in the U.S.A.
- 5 years limited warranty
Model #* |
Supported Cameras |
Storage Size |
DW-BJP1U10T
|
Up to 64 2.1MP IP Cameras
|
10TB
|
DW-BJP1U20T |
Up to 64 2.1MP IP Cameras
|
20TB
|
DW-BJP1U30T |
Up to 64 2.1MP IP Cameras
|
30TB
|
Downloads
Specifications
Maximum IP cameras | 64 (2.1MP/1080p @30fps, with medium recording quality) | |
Included IP licenses | 4 | |
Form factor | Rack mount | |
Operating system | Windows® 10 IoT | DW-BJP1UXT |
Linux Ubuntu® 64 bit | DW-BJP1UXT-LX | |
OS on SSD | 150GB SSD | |
CPU | Intel® i5® processor | |
Option: DW-CPUI7 - upgrade processor to i7* | ||
Memory | 8GB | |
Ethernet port | 2x gigabit ethernet ports (RJ45) | |
System | Max video storage rate (Mbps) | 360 Mbps |
Storage | Maximum hard drives | 1 x SSD + 3 x HDD |
Maximum storage | 30TB | |
Video-out | Outputs | True HD output or VGA or DVI |
Video card | GeForce 210 512MB | |
Option: DW-RV4H - 4 head HD video card* | ||
Resolution | HD 1080p | |
Pre-loaded VMS software | DW Spectrum® IPVMS | |
Remote clients | Cross platform - Windows®, Linux Ubuntu® and Mac® | |
Mobile apps | iOS® and Andriod® | |
Keyboard & mouse | Included | |
Rail kit | Included | |
Power supply | 300W** | |
Operating temperature and humidity | 41°F~104°F (5°C~40°C) | |
Operating humidity | 20~90% RH | |
Dimension (WxDxH) | 17.25” x 26.5” x 1.75” (438.15 x 673.1 x 44.45 mm) | |
Warranty | 5 year limited |
Additional Information
Channel Capacity: |
64 camera channels
|
Pre-Installed Storage: |
30 TB
|
Product Series: |
Blackjack P-Rack
|
Recorder Technology: |
Network Video Recorder (NVR)
|
Warranty: |
5-year Manufacturer Warranty
|
