Digital Watchdog DW-VP123T8P 8-channel VMAX IP Plus PoE Network Video Recorder with 4 virtual channels, 3TB HDD included

Part Number: DW-VP123T8P
Write a Review
Check other similar products:
Discontinued
  • Digital Watchdog DW-VP123T8P 8-channel VMAX IP Plus PoE Network Video Recorder with 4 virtual channels, 3TB HDD included - 1
  • Digital Watchdog DW-VP123T8P 8-channel VMAX IP Plus PoE Network Video Recorder with 4 virtual channels, 3TB HDD included - 2
  • Digital Watchdog DW-VP123T8P 8-channel VMAX IP Plus PoE Network Video Recorder with 4 virtual channels, 3TB HDD included - 3
  • Digital Watchdog DW-VP123T8P 8-channel VMAX IP Plus PoE Network Video Recorder with 4 virtual channels, 3TB HDD included - 4
Free shipping over $300 Free Shipping
Technical Support Technical Support
5 Year Warranty 5 Year Warranty
  • Compression : H.265, H.264,
  • Pre-Installed Storage : 3 TB
  • Video Output : 1x HDMI 1x VGA
  • Max. Recording Resolution : 4K
  • Hard Drive Ports : 4 SATA Ports
  • Max. Storage Capacity : 32 TB Storage Capacity
  • Color : Black
  • Environmental : Indoor
  • Number of PoE Ports : 8 PoE Ports
  • Power Budget : 360 Watt

Description

Digital Watchdog DW-VP123T8P 8-channel VMAX IP Plus PoE Network Video Recorder with 4 virtual channels, 3TB HDD included

The VMAX® IP Plus™ is an easy to use PoE NVR that allows you to go from power up to monitoring in less than three minutes! Combine with the DW Witness™ app to turn the camera on a smartphone or tablet into a surveillance camera that can be viewed and recorded on the NVR. Available with 8 PoE ports (expandable to 12 cameras), the NVRs can record and manage single-sensor IP cameras up to 4K, with 80Mbps maximum throughput.

Key Features:

  • Complete installation, setup and camera configuration in under three minutes!
  • CCIP™ system encryption protects your surveillance system from out of network attacks
  • Record and manage single-sensor IP cameras at real-time 30fps up to 4K (3840×2160), with 80Mbps maximum throughput
  • Local power for up to 8 IP cameras via resident PoE switch
  • myDW® Cloud Management Services
  • DW Witness™ turns a smartphone or tablet into an additional surveillance camera
  • PathFinder™ Peer-to-Peer (P2P) remote connection
  • Automatic device discovery
  • Control any ONVIF™ camera’s setup and features remotely
  • 3TB HDD included
  • Snapshot Notify™: programmable interval camera image verification sent to an email
  • Remote management with C3™ CMS software up to 288 channels
  • Event notifications via email, text and C3™ CMS and push notifications to mobile devices
  • Mobile Application for iOS® and Android® devices and Apple TV®
  • Dual-stream recording
  • Easy drag and drop camera management
  • Instant backup during playback
  • 4K output for local live and playback display
  • Complete analysis with real-time system, network and PoE monitoring
  • True HD and VGA simultaneous output support
  • 16 sensor inputs, 4 alarm relay outputs
  • Advanced H.265, H.264 Linux embedded NVR
  • NVR calculation and auto-recording configuration
  • Add public view monitors with Spot Monitoring Modules
  • Help menu on major functions
  • Auto or manual firmware upgrade available
  • Screen saver to protect monitor screen
  • Import/export configuration between multiple NVRs
  • USB mouse and GUI control
  • 5 year limited warranty
  • Compatible Accessories:
  • DW-VR19E 19in rack mount ears
  • DW-VP16RE 19in rack mount ears
  • DWSP-VACREMOTE Remote control for VMAX recorders
  • DW-KB100 System Control Keyboard
  • DW-POE896M PoE Switch 8 Channel Accessory

Compatible products

Video recorders will require additional parts in order to perform their function. CCTV Power supply, PoE Switches, hard drives, wireless mouse, recorder mount accessories and cables are just few to be mentioned. If you have any questions to complete your security camera system, please check with our sales team first. You can call us at (866) 441-2288 or email us at sales@a1securitycameras.com with any design questions.

Additional Information

4K Support:
4K Supported
Alarm Input:
16 Channel
Alternative SKUs:
DW-VP12xT8P
Audio Input:
1x Channel
Audio Output:
1x Channel
Certifications:
CE FCC KCC WEEE RoHS UL Listed
Channel Capacity:
12 Channels
Color:
Black
Compatible Integration (API):
ONVIF
Compression:
H.265 H.264
Connection Type:
Wired
Dimensions:
440 x 397.8 x 70 mm (17.32 x 15.66 x 2.79 in)
Environmental:
Indoor
Hard Drive Ports:
4 SATA Ports
Included Licenses:
4 Licenses
LED Indicator:
Status LED
Max. Recording Resolution:
4K
Max. Storage Capacity:
32 TB
Mounting:
Rack Mount
Network Interface:
1x RJ-45
Number of PoE Ports:
8 PoE Ports
Operating Humidity:
20% to 90% RH
Operating System:
Embedded LINUX
Operating Temperature:
5 °C to 40 °C (41 °F to 104 °F)
PoE Standards:
IEEE 802.3at
Power Budget:
360 Watt
Power Supply:
110 to 240 V AC
Power for each port:
30W
Pre-Installed Storage:
3 TB
Product Series:
Digital Watchdog VMAX IP Plus Series
Rack Unit (U):
1.5U
Recorder Technology:
Network Video Recorder (NVR)
Relay Output:
4 Channels
Serial Interface:
1x RS232 1x RS485
USB Interface:
1x USB 3.0 1x USB 2.0
Video Output:
1x HDMI 1x VGA
Warranty:
5-year Manufacturer Warranty
e-SATA:
e-SATA
