ENS 4 Channel 4PoE 4K H.265 Lite Network Video Recorder, No HDD included - NVR301HS-04/P-4KS2/L

Part Number: NVR301HS-04/P-4KS2/L
Write a Review
  • ENS 4 Channel 4PoE 4K H.265 Lite Network Video Recorder, No HDD included - NVR301HS-04/P-4KS2/L - 1
  • ENS 4 Channel 4PoE 4K H.265 Lite Network Video Recorder, No HDD included - NVR301HS-04/P-4KS2/L - 2
  • ENS 4 Channel 4PoE 4K H.265 Lite Network Video Recorder, No HDD included - NVR301HS-04/P-4KS2/L - 3
$199.99
Technical Support Technical Support
  • Compression : H.265, H.265 Plus, H.264, H.264 Plus, Smart H.264, Smart H.264 Plus, Smart H.265, Smart H.265 Plus,
  • Pre-Installed Storage : No HDD included
  • Video Output : 1x VGA 1x HDMI
  • Max. Recording Resolution : 4K
  • Hard Drive Ports : 1 SATA Port
  • Max. Storage Capacity : 10 TB Storage Capacity
  • Color : White
  • Number of PoE Ports : 4 PoE Ports

Description

ENS 4 Channel 4PoE 4K H.265 Lite Network Video Recorder, No HDD included - NVR301HS-04/P-4KS2/L

NVR301HS-04/P-4KS2/L is introduced as the Lite series NVR that supports for 4K and H.265 encoding technology with excellent performance at an affordable price. For applications where image details are highly required, it delivers the capability of 4K resolution processing. The NVR can be served as edge storage, central storage or backup storage with an intuitive shortcut operation menu for remote management and control.

Due to its cost-effective and easy-to-install design, this NVR is ideal for a wide range of applications such as public safety, water conservancy, transportation, city centers, education, and financial institutions. The NVR is compatible with numerous third-party devices making it the perfect solution for surveillance systems that work independently of video management system (VMS). It features an open architecture that supports for multi-user access and is compatible with ONVIF Profile S, T, G protocol, enabling interoperability with IP cameras.

Key Features:

  • New 4.0 user interface, Security baseline 2.1
  • H.264, H.265, Smart H.264+, and Smart H.265+. H.265 auto switch
  • Max. decoding capability: 8 × 1080p@30 fps. Supports adaptive decoding
  • Supports mainstream cameras of ONVIF and RTSP protocols
  • P2P remote surveillance, video play on mobile device
  • VGA/HDMI simultaneous video output, maximum resolution of HDMI is 4K
  • AI by Camera: Face detection, perimeter protection, IVS, people counting, heat map, and SMD
  • Supports remote configuration and management of IPC, such as set ting parameters, getting information, and upgrading IPC of the same model in batches

Compatible products

Video recorders will require additional parts in order to perform their function. CCTV Power supply, PoE Switches, hard drives, wireless mouse, recorder mount accessories and cables are just few to be mentioned. If you have any questions to complete your security camera system, please check with our sales team first. You can call us at (866) 441-2288 or email us at sales@a1securitycameras.com with any design questions.

Additional Information

4K Support:
4K Supported
Audio Compression:
PCM G.711a G.711u G.726 AAC
Audio Input:
1x RCA
Audio Output:
1x RCA
Capacity for each disk:
up to 10TB
Channel Capacity:
4 Channels
Color:
White
Compatible Integration (API):
ONVIF Profile S ONVIF Profile G ONVIF Profile T CGI Conformant SDK
Compression:
H.265 H.265 Plus H.264 H.264 Plus Smart H.264 Smart H.264 Plus Smart H.265 Smart H.265 Plus
Connection Type:
Wired
Dimensions:
204.6 x 206.4 x 48.1 mm (8.06 x 8.12 x 1.90 in)
Hard Drive Ports:
1 SATA Port
Languages:
English
Max Power Consumption:
10 Watts
Max. Incoming Bandwidth:
80Mbps
Max. Recording Resolution:
4K
Max. Storage Capacity:
10 TB
Mobile Apps:
Android iOS
Mounting:
Desktop Mount
Network Interface:
1x RJ-45 10M/100M self-adaptive Ethernet interface
Number of PoE Ports:
4 PoE Ports
Operating Humidity:
10% to 93%
Operating Temperature:
-10 °C to 50 °C (14 °F to 122 °F)
Outgoing Bandwidth:
60 Mbps
Power Supply:
48 VDC
Power for each port:
25.5W
Pre-Installed Storage:
No HDD included
Product Series:
ENS Lite Series
Recorder Technology:
Network Video Recorder (NVR)
USB Interface:
2x USB 2.0
Video Output:
1x VGA 1x HDMI
Web Browser:
Chrome Internet Explorer 9 or above Firefox
