Description
ENS 4 Channel 4PoE 4K H.265 Lite Network Video Recorder, No HDD included - NVR301HS-04/P-4KS2/L
NVR301HS-04/P-4KS2/L is introduced as the Lite series NVR that supports for 4K and H.265 encoding technology with excellent performance at an affordable price. For applications where image details are highly required, it delivers the capability of 4K resolution processing. The NVR can be served as edge storage, central storage or backup storage with an intuitive shortcut operation menu for remote management and control.
Due to its cost-effective and easy-to-install design, this NVR is ideal for a wide range of applications such as public safety, water conservancy, transportation, city centers, education, and financial institutions. The NVR is compatible with numerous third-party devices making it the perfect solution for surveillance systems that work independently of video management system (VMS). It features an open architecture that supports for multi-user access and is compatible with ONVIF Profile S, T, G protocol, enabling interoperability with IP cameras.
Key Features:
- New 4.0 user interface, Security baseline 2.1
- H.264, H.265, Smart H.264+, and Smart H.265+. H.265 auto switch
- Max. decoding capability: 8 × 1080p@30 fps. Supports adaptive decoding
- Supports mainstream cameras of ONVIF and RTSP protocols
- P2P remote surveillance, video play on mobile device
- VGA/HDMI simultaneous video output, maximum resolution of HDMI is 4K
- AI by Camera: Face detection, perimeter protection, IVS, people counting, heat map, and SMD
- Supports remote configuration and management of IPC, such as set ting parameters, getting information, and upgrading IPC of the same model in batches
Downloads
Compatible products
Additional Information
4K Support:
|
4K Supported
|
Audio Compression:
|
PCM
G.711a
G.711u
G.726
AAC
|
Audio Input:
|
1x RCA
|
Audio Output:
|
1x RCA
|
Capacity for each disk:
|
up to 10TB
|
Channel Capacity:
|
4 Channels
|
Color:
|
White
|
Compatible Integration (API):
|
ONVIF Profile S
ONVIF Profile G
ONVIF Profile T
CGI Conformant
SDK
|
Compression:
|
H.265
H.265 Plus
H.264
H.264 Plus
Smart H.264
Smart H.264 Plus
Smart H.265
Smart H.265 Plus
|
Connection Type:
|
Wired
|
Dimensions:
|
204.6 x 206.4 x 48.1 mm (8.06 x 8.12 x 1.90 in)
|
Hard Drive Ports:
|
1 SATA Port
|
Languages:
|
English
|
Max Power Consumption:
|
10 Watts
|
Max. Incoming Bandwidth:
|
80Mbps
|
Max. Recording Resolution:
|
4K
|
Max. Storage Capacity:
|
10 TB
|
Mobile Apps:
|
Android
iOS
|
Mounting:
|
Desktop Mount
|
Network Interface:
|
1x RJ-45 10M/100M self-adaptive Ethernet interface
|
Number of PoE Ports:
|
4 PoE Ports
|
Outgoing Bandwidth:
|
60 Mbps
|
Power Supply:
|
48 VDC
|
Power for each port:
|
25.5W
|
Pre-Installed Storage:
|
No HDD included
|
Product Series:
|
ENS Lite Series
|
Recorder Technology:
|
Network Video Recorder (NVR)
|
USB Interface:
|
2x USB 2.0
|
Video Output:
|
1x VGA
1x HDMI
|
Web Browser:
|
Chrome
Internet Explorer 9 or above
Firefox
|
