ETS ML1 ML1-TD Outdoor Panel Mount Omni-Directional Microphone

ETS ML1 ML1-TD Outdoor Panel Mount Omni-Directional Microphone

The ETS ML1-TD is a high-performance, low-cost omni-directional electret microphone from the ETS ML1 Series, designed for panel mounting and built for IP cameras that accept microphone-level input signals. It is also compatible with standard PC microphone inputs. The IP54-rated anodized aluminum housing is both weather resistant and tamper resistant, allowing the microphone to be installed in exposed or public-facing locations.

Its omni-directional pattern picks up sound from every direction, with a 40 Hz to 17 kHz frequency response, -44 dB sensitivity, a 60 dB signal-to-noise ratio, and a maximum SPL of 120 dB. The ML1-TD delivers a -40 dB mic-level output into a 2-5k ohm load and runs on 2-10 VDC supplied directly by the connected camera, so no separate power supply is needed. It is rated to operate from -40°F to 185°F.

The microphone ships with a 6 ft attached cord terminated in a stereo 3.5mm connector, along with a mounting locknut, two washers, and an audio surveillance warning label. Longer cables up to 25 ft, a flying lead output for cameras with terminal blocks (-FL), and a higher performance capsule (-LN) are available under separate part numbers. Installers and end users are responsible for deploying audio surveillance in compliance with state and federal privacy laws. The ML1-TD is made in the USA and backed by a 1-year parts and labor warranty.

Key Features:

• Omni-directional electret capsule; captures sound evenly from all directions for full-area audio coverage.
• IP54 weather-resistant rating; withstands dust and water splashes in outdoor and semi-exposed installations.
• Tamper-resistant anodized aluminum housing; helps prevent vandalism in exposed locations.
• 40 Hz to 17 kHz frequency response; reproduces speech and ambient sound with natural clarity.
• -44 dB sensitivity and 60 dB S/N ratio; delivers clean mic-level audio to the connected camera.
• 120 dB max SPL; handles loud environments without distortion.
• Camera-powered 2-10 VDC operation; eliminates the need for a separate power supply.
• 6 ft cord with stereo 3.5mm connector; plugs directly into IP camera and PC microphone inputs.
• -40°F to 185°F operating temperature; performs reliably in extreme climates.
• Made in USA with 1-year parts and labor warranty; provides dependable build quality and support.
