ETS ML1-U Flush Mount Uni-directional Microphone

ETS ML1-U Flush Mount Uni-directional Microphone

The ML1-U is a low cost uni-directional electret microphone for use with IP cameras accepting microphone level input signals (PC compatible input). The attached cord is 6' long and comes standard with a stereo 3.5mm connector on one end.

Add -FL to the P/N for a flying lead output for connections to cameras with terminal blocks. For use with IP cameras accepting microphone level inputs (the camera supplies power to ECM cartridge)

With a 6-feet cord, this ETS ML1-U microphone also has a 3.5mm connector. The connector is detachable which makes it easy to connect the cord directly to cameras with terminal blocks. It features a standard electrical "single gang" cover plate and a fire suppression sprinkler head appearance. The ETS ML1-U Flsuh Mount Uni-Directional Surveillance Microphone can be surface mount, ensuring easy installation.

Key Features:

• 15' Pickup Pattern: picks up audio signals from 15 feet
• Removable Connector: helps connect the cord directly to cameras with terminal blocks
• 6' Cord: allows ease of movement
• Uni-directional pattern
• Max SPL 120db
• Frequency response: 150-16khz
• Sensitivity –54db
• -40db output (mic level)
• 2-10Vdc operation
• 680-5k Ohm load resistance
• S/N 60db
• 3.5mm stereo connector
• White Plastic plate, Aluminum mic holder
• Operating temperature –30 to 70C
• Weight: 0.025 lbs
