ETS ML1-W Weather Resistant Surface mount Omni-directional Microphone

Brand: ETS
Part Number: ML1-W
Write a Review
  • ETS ML1-W Weather Resistant Surface mount Omni-directional Microphone
  • ETS ML1-W Weather Resistant Surface mount Omni-directional Microphone
Technical Support Technical Support
1 Year Warranty 1 Year Warranty
  • Direction : Omni-directional
  • Color : Gray
  • Environmental : Outdoor


ETS ML1-W Outdoor Surveillance Microphone

The ML1-W is a low cost, weather resistant omni-directional electret microphone for use with I/P cameras accepting microphone level input signals (PC compatible input). The attached cord is 6' long and comes standard with a stereo 3.5mm connector on one end.The ML1-W's 3.5mm connector can be removed and the cord can be directly connected to cameras with terminal blocks.

Key features:

  • Omni-directional pattern
  • Max SPL 120db
  • Frequency response: 20-18khz
  • Sensitivity -50db
  • 1.5-10Vdc operation
  • 300-5k Ohm load resistance
  • S/N 40db
  • 3.5mm stereo connector
  • 1/2″ thick removable windscreen.
  • Aluminum and plastic housing
  • Weight: 0.125 lbs
Package Includes:
  • ML1-W microphone.
  • Gasket
  • Warning label.
  • 6' cable length
  • Custom cable lengths up to 25' available.

Note: Camera must accept electret type microphone inputs (camera supplies power to ECM cartridge)



All of ETS items are special built to order items. The moment the order is sent to ETS, they will start production/building. This will take around 1-2 weeks depending on the line of production, volume of your order, etc. Please plan accordingly. We will enter tracking as soon as it becomes available to us. If you have any questions feel free to contact the customer service team at or call us at 214-948-1300 x 411.


Datasheet ets-ml1-w-A1.pdf

Additional Information

Audio Surveillance Type:
Microphone Surveillance Microphones
Surface Mount
1-year Manufacturer Warranty
