ETS SA1-LPEA IP Camera Interface and 70V / 8 Ohm Speaker Driver
The SA1-LPEA is a PoE in-line, 2.5W speaker driver, I/P camera interface that taps power off the camera's Ethernet CAT5 cable for talk-back only, public address and security applications. 3.5mm (or RCA) input jack for connection to "line output" of I/P cameras. Supports both modes A and B of IEEE802.3af.
Key Features:
- RCA or 3.5mm audio input connector
- Transformer isolated, line level audio input.
- Adjustable speaker volume level control.
- 2.5 Watt speaker power amplifier.
- Internal 70V 2.5Watt speaker transformer.
- Switch selectable 70v or 8 Ohm speaker mode.
- RJ45 Ethernet in/out jacks
- Straight through CAT5 connections (no crossover)
- A/B mode switch for IEE802.3af power format.
- Internal switching regulator converts POE 48Vdc to 15Vdc for internal speaker power amplifier.
- Euro-style connector makes speaker cable terminations fast and clean.
- Current consumption 40ma. Maximum
- Led power indicator.
- Auto polarity protected & fused.
- Dimensions: L 5.3 x W 3.3 x H 1.6
Includes
- SA1-LPEA Speaker driver.
- 1 each 6’ RCA or 3.5mm patch cable.
- Installation instructions.
Options
- SA1-LPEA 3.5mm connector/patch
- SA1-LPEA-RCA RCA connector/patch
- SA1-LPEA-FL Flying leads for screw terminal blocks.
Wiring Requirements
- Speaker cable run: stranded 22- gauge, 2-conductor:
- 70V mode: cable: 1000 feet max
- 8 Ohm mode: 100 feet max.
IMPORTANT
NOTE
All of ETS items are special built to order items. The moment the order is sent to ETS, they will start production/building. This will take around 1-2 weeks depending on the line of production, volume of your order, etc. Please plan accordingly. We will enter tracking as soon as it becomes available to us. If you have any questions feel free to contact the customer service team at customerservice@a1securitycameras.com or call us at 214-948-1300 x 411.
