Geovision GV-RK1352 Card Reader with Keypad - 520-RK1352-000

Brand: Geovision
Part Number: GV-RK1352
Write a Review
  • Geovision GV-RK1352 Card Reader with Keypad - 520-RK1352-000
  • Geovision GV-RK1352 Card Reader with Keypad - 520-RK1352-000
  • Geovision GV-RK1352 Card Reader with Keypad - 520-RK1352-000
$123.00

Help me pick a security camera

Technical Support Technical Support
3 Year Warranty 3 Year Warranty
  • Protection Code : IP66
  • Color : Black
  • Environmental : Outdoor
  • Access Control Type : Card Readers

Description

Geovision GV-RK1352 Card Reader with Keypad

The GV-RK1352 is a card reader with keypad, designed to recognize PIN codes, identification cards or both. Featured with the Wiegand and RS-485 outputs, the unit can be connected to any standard access control panel. GV-RK1352 comes with a weather sealed and IP66 compliant housing for outdoor use.

Key features:

  • Card reader with keypad
  • Identification card and PIN code recognition
  • Weather-proof and IP66-compliant housing
  • RS-485 output: 9,600 bps, connect up to 8 GV-RK1352 units
  • 13.56MHz for ISO14443A (MIFARE DESFire, MIFARE Plus and MIFARE Classic)

Packing List:

  • GV-RK1352 Card Reader
  • Screw x 2
  • Screw Anchor x 2
  • Front Cover Plate x 2
  • Software CD
  • Warranty Card

Compatible Mount:

  • Geovision GV-MountA900 (150-MTA900-000) mounting plate for single-gang power box (for GV-AS110 or GV-RK1352 Card Reader)

Notes:

  1. 1. RS485 interface only supports GeoVision controllers, while Wiegand interface supports both GeoVision and 3rd party controllers (Wiegand 26/34 Bits).
  2. 2. UL 294 Attack Class Level 1 depends on other connected equipment.
  3. 3. If you are using third-party cards or key fobs, the reader must be under UID mode.
  4. 4. Specifications are subject to change without notice.

Ordering Number: 520-RK1352-000

SKU: 55-RK13520-0101

Specifications

CPU 8-bit microprocessor
Frequency 13.56 MHz for ISO14443A ( MIFARE DESFire , MIFARE Plus and MIFARE Classic )
Wiegand Interface Wiegand 26 / 34 bits, distance 30 m (98.43 ft)
RS-485 9,600 bps, connect up to 8 GV-RK1352 units
Power Source DC 7.5V~12V
Power Consumption 60 mA
LED Red, Green and Blue LED
Beeper Buzzer
Color Black
Supported ID Formats Reads GID and UID
Operating Temperature -35 °C ~ 65 °C (-31 °F ~ 149 °F)
Operating Humidity 10 ~ 90% RH (non-condensing)
Dimensions (W x H x D) 95 x 108 x 23 mm (3.74 x 4.25 x 0.91 in)
Weight 260 g / 0.57 lb
Ingress Protection IP66
Certification CE, FCC, RoHS
View AllClose

Compatible products

Camera mounts - enclosures are essential to install security cameras. Each surface will require different type of mount and bracket combination. Please check with our sales team if you need help. You can call us at (866) 441-2288 or email us at [email protected] with any design questions.

Additional Information

Access Control Type:
Card Readers
Color:
Black
Durability:
Weatherproof
Environmental:
Outdoor
NDAA Compliance:
NDAA Compliant
Protection Code:
IP66
Read Format:
13.56 mHz
Warranty:
3-year Manufacturer Warranty
