Geovision GV-800-16 16-Camera DVR Video Capture Card
Geovision has come up with an excellent DVR card, the Geovision GV-800-16 16-camera DVR Video Capture Card. This DVR card offers one of the highest recording frame rates. It offers 16 camera inputs and 4 audio inputs. It is easy to install setup and configure and is very reliable too. The GV-800-16 can connect up to 16 cameras at a time and expand up to 32 channels by adding 16 Geovision IP cameras. This DVR card uses the latest audio and video dongles as well as the latest GeoVision software. This capture card can retrieve live video data and store it to your hard drive or network drive for archival purposes. This capture card supports both NTSC and PAL video formats.
The GV-800-16 uses the PCI express card interface. The recording resolution for this capture card is 320 x 240 at 120fps for CIF and 720 x 480 at 60 fps for D1. The best part of the GV-800-16 is that it can be controlled by laptops, iPhones, android or even a TabletPC. The Geovision GV-800-16 16-camera DVR Video Capture Card supports compression formats H.264 and MPEG4.
Key Features of the Geovision GV-800-16 16-camera DVR Video Capture Card
  • Recording Rate: highest recording rate from 16 camera inputs and 4 audio inputs
  • Display Rate: the CIF resolution in NTSC format allows 120fps and in the PAL format allows 100fps
  • Video Resolution: allows a resolution of 704x480, 704x480 De-interlace, 640x480, 640x480 De-interlace, 352x240, 320x240 in NTSC format and 704x576, 704x576 De-interlace, 640x480, 640x480 De-interlace, 352x288, 320x240 in PAL format
  • Dimensions: by the L XWXH format the dimension is 120 x 82 mm / 4.7 x 3.2 in

This product is also associated with:
Geovision

Features

Manufacturer:
Geovision
Product Type:
Accessories
Warranty:
3-year Manufacturer Warranty
Discontinued:
no

Video Recorder Features

Number of camera channels:
  • 16 camera channels
Hard Drive Ports:
16 SATA Ports
Technical Specs

Geovision GV-800-16 16-camera DVR Video Capture Card Specifications
  • Interface: PCI-E (x1)
  • Input Type: DVI
  • Video Input: GV-800B-16 Cams
  • Audio Input: 4 Channels, 8 Channels
  • Recording Rate CIF: GV-800B-NTSC 16-port: 120 fps, PAL- 16-port: 100 fps
  • Recording Rate D1: NTSC 16-port: 60 fps, PAL 16-port: 50 fps
  • Display Rate CIF:  NTSC - 16-port: 120 fps, PAL- 16-port: 100 fps,
  • Display Rate D1:  NTSC-4-port: 120 fps 16-port: 60 fps 16+16 port: 120 fps, PAL-4-port: 100 fps 16-port: 50 fps  16+16 port: 100 fps
  • Video Resolution: NTSC-704x480, 704x480 De-interlace, 640x480, 640x480 De-interlace, 352x240, 320x240, PAL: 704x576, 704x576 De-interlace, 640x480, 640x480 De-interlace, 352x288, 320x240
  • Video Compression Format: Geo MPEG4, Geo H264
  • Audio Format: 16 kHz / 16-bit, 32 kHz / 16-bit)
  • GV-NET/IO Card Support: Yes
  • Dimensions (W x H) PCI-E: 120 x 82 mm / 4.7 x 3.2 in
  • Installation Guide: GV-800B
  • OS Supported: 32-bit-Windows XP / Vista / 7 / 8 / Server 2008, 64 bit-Windows 7 / 8 / Server 2008 R2 / Server 2012
  • CPU: Pentium 4, 3.0 GHz with Hyper-Threading
  • RAM: Windows XP: 2 x 512 MB Dual Channels Windows Vista / 7 / 8 / Server 2008 / Server 2012 : 2 x 1 GB Dual Channels
  • HDD: 80 GB
  • Graphic Card: AGP or PCI-Express, 800 x 600 (1280 x 1024 recommended), 32-bit color
  • DirectX: 9.0c
Datasheets

Geovision GV800B-16 Datasheet (Datasheet_800B.pdf, 155 Kb) [Download]
