Geovision UA-XVL1610 16 Channel 5MP H265 Digital Video Recorder, HDD Not Included

Brand: Geovision
Part Number: UA-XVL1610
Write a Review
Replacement: There is no direct replacement. Ask a representative.
Check other similar products:
Geovision Video Recorders
NDAA Compliant Cameras
Geovision Video Recorders DVR
Discontinued
  • Geovision UA-XVL1610 16 Channel 5MP H265 Digital Video Recorder, HDD Not Included - 2
  • Geovision UA-XVL1610 16 Channel 5MP H265 Digital Video Recorder, HDD Not Included - 3
  • Geovision UA-XVL1610 16 Channel 5MP H265 Digital Video Recorder, HDD Not Included - 4
  • Geovision UA-XVL1610
Free shipping over $300 Free Shipping
Technical Support Technical Support
2 Year Warranty 2 Year Warranty
  • Compression : H.265, H.264,
  • Max. FPS and Resolution : 12fps at 2592 x 1944
  • Pre-Installed Storage : No HDD included
  • Video Output : 1x HDMI 1x VGA
  • Max. Recording Resolution : 5MP (3K)
  • Hard Drive Ports : 1 SATA Port
  • Max. Storage Capacity : 8 TB Storage Capacity
  • Color : Black
  • Environmental : Indoor

Related Products

Description

Geovision UA-XVL1610 16 Channel 5MP H265 Digital Video Recorder, HDD Not Included

UA-XVL1610 is a powerful H.264 / H.265 HD DVR with compact size and supports 16-channel analog camera and 4-channel IP camera inputs, totaling a connection of up to 20 channels. It converts analog signals into high-resolution digitized images up to 5 megapixels. Featuring 4-in-1 video output, UA-XVL1610 supports TVI/AHD/CVI connection.With its Web Client on the web browser, users can access several functions, including Live View, Change Stream, Manual Alarm, Divide Screen, and more. It is also able to trigger Tampering Alarm alerts when cameras are tampered with, which can prevent criminal activities.

Key Features:

  • H.265 / H.264 video format
  • 16-ch TVI / AHD / CVI video input
  • 4-ch IP camera input
  • 1-ch HDMI, 1-ch VGA, HDMI at up to 4K (3840 x 2160) resolution
  • HDMI and VGA simultaneous output
  • 1 SATA HDD, up to 8 TB
  • 4 alarms inputs and 1 alarm output
  • P2P function for GV-Eye app
  • ONVIF cameras support

Downloads

Popular Search

Geovision Video Recorders
NDAA Compliant Cameras
Geovision Video Recorders DVR

Additional Information

Alarm Input:
4 Channel
Alarm Output:
1 Channel
Audio Capability:
One-way Audio
Audio Compression:
G.711
Audio Input:
4x RCA
Audio Output:
1x RCA
Capacity for each disk:
up to 8TB
Certifications:
CE FCC LVD RoHS UKCA
Channel Capacity:
16 Channels
Color:
Black
Compatible Integration (API):
ONVIF
Compliance:
NDAA Compliant
Compression:
H.265 H.264
Connection Type:
Wired
Dimensions:
300 x 219.7 x 52.5 mm (11.81 x 8.64 x 2.06 in)
Disk Form Factor:
3.5"
Environmental:
Indoor
Hard Drive Ports:
1 SATA Port
Max Power Consumption:
13.8 Watts
Max. FPS and Resolution:
12fps at 2592 x 1944
Max. Incoming Bandwidth:
80Mbps
Max. Recording Resolution:
5MP (3K)
Max. Storage Capacity:
8 TB
Mobile Apps:
GV-Eye iOS Android
Mounting:
Standalone
Network Interface:
1x RJ-45 10/100/1000 Mbps
Operating Humidity:
0% to 90% RH
Operating System:
Embedded LINUX
Operating Temperature:
0 °C to 40 °C (32 °F to 104 °F)
Outgoing Bandwidth:
96 Mbps
Power Supply:
12 VDC
Pre-Installed Storage:
No HDD included
Product Series:
Geovision USAVision Series
Recorder Technology:
Digital Video Recorder (DVR)
Serial Interface:
1x RS485
USB Interface:
1x USB 2.0 1x USB 3.0
Video Input:
16x BNC
Video Output:
1x HDMI 1x VGA
Warranty:
2-year Manufacturer Warranty
