Hanwha Vision HRX-1635-36TB 16 Channel 8MP Pentabrid DVR with 36TB HDD Included

Part Number: HRX-1635-36TB
Write a Review
  • Hanwha Vision HRX-1635-36TB 16 Channel 8MP Pentabrid DVR with 36TB HDD Included
  • Hanwha Vision HRX-1635-36TB 16 Channel 8MP Pentabrid DVR with 36TB HDD Included
  • Hanwha Vision HRX-1635-36TB 16 Channel 8MP Pentabrid DVR with 36TB HDD Included
  • Hanwha Vision HRX-1635-36TB 16 Channel 8MP Pentabrid DVR with 36TB HDD Included
$5,687.00
$4,164.72
— You save $1,522.28
Free shipping over $300 Free Shipping
Technical Support Technical Support
  • Compression : H.265, H.264, MJPEG,
  • Pre-Installed Storage : 36 TB
  • Max. Recording Resolution : 8MP (4K)
  • Hard Drive Ports : 8 SATA Ports
  • Max. Storage Capacity : 48 TB Storage Capacity
  • Color : Black

Description

Hanwha Vision HRX-1635-36TB 16 Channel 8MP Pentabrid DVR with 36TB HDD Included

The Hanwha Vision HRX-1635-36TB is a high-performance 16-channel Pentabrid DVR engineered for hybrid surveillance systems that integrate analog and IP cameras. It supports AHD, HDTVI, HDCVI, CVBS, and IP inputs, accommodating up to 18 total channels (16 analog + 2 IP). With 36TB HDD Included and scalability up to 48TB through 8 SATA drives, the system offers extensive storage for long-term video retention. It supports up to 8MP recording resolution and utilizes H.265, H.264, and MJPEG compression to maximize efficiency. HDMI and VGA outputs support simultaneous 4K and Full HD local display. Advanced event detection, intelligent network camera search, and remote access through Wisenet platforms make the HRX-1635-36TB an ideal solution for professional surveillance deployments.

Key Features:

  • 16 Channels; supports 16 analog inputs and 2 additional IP channels, up to 18CH total
  • 8MP Recording Resolution; delivers ultra-high-definition video for critical surveillance
  • 36TB HDD Included; supports scalable storage up to 48TB with 8 SATA drive bays
  • H.265, H.264, and MJPEG Compression; maximizes recording efficiency and storage usage
  • HDMI and VGA Outputs; allows dual monitor support with up to 4K and Full HD resolutions
  • 128Mbps Recording Bandwidth; ensures smooth performance for multi-channel recording
  • Smart Event Triggers; includes motion detection, tampering, video loss, and IP camera analytics
  • Smart Search (Network Cameras); enables fast, event-based review of recorded footage
  • Coaxial Control Support; allows PTZ functionality over analog video formats
  • USB and Network Backup; supports secure export in multiple file formats
  • Remote Access; via Wisenet Mobile app, WebViewer, SSM, and Wisenet Viewer platforms
  • Embedded Linux OS; offers stability and 24/7 operational reliability
  • 2-Way Audio Support; includes 16 audio input channels and 1 output for enhanced monitoring
  • Advanced Security Features; includes user permissions, encryption, IP filtering, and access logs

Additional Information

Capacity for each disk:
up to 6TB
Channel Capacity:
16 Channels
Color:
Black
Compression:
H.265 H.264 MJPEG
Connection Type:
Wired
Dimensions:
440 x 88 x 384.8 mm (17.32 x 3.46 x 15.15 in)
Hard Drive Ports:
8 SATA Ports
Max. Recording Resolution:
8MP (4K)
Max. Storage Capacity:
48 TB
Operating Humidity:
20% to 85% RH
Operating Temperature:
0 °C to 40 °C (32 °F to 104 °F)
Power Supply:
100 to 240 V AC
Pre-Installed Storage:
36 TB
Recorder Technology:
Digital Video Recorder (DVR)
