Hanwha Vision HV-X530L-18GHXM-90 16 Port Gigabit PoE++ Managed Switch with 720W
The Hanwha Vision HV-X530L-18GHXM-90 is a fully managed 16-port Gigabit Ethernet PoE++/PoE+ switch with a 720W total PoE budget and dual 10GB SFP+ uplink ports, purpose-built for demanding Hanwha surveillance installations. Running AW+ OS with CLI, GUI, and NetCONF/RESTCONF support, it delivers enterprise-grade management flexibility across a wide range of network environments.
Advanced capabilities include static and multicast routing, tri-authentication (MAC-based, web-based, and IEEE 802.1x), Virtual Chassis Stack support for up to 8 units, EPSR Master or Transit redundancy, active fiber monitoring, and QoS classification — making it an ideal backbone switch for large-scale, high-availability surveillance networks optimized for Hanwha network cameras.
Key Features:
- 16 PoE++/PoE+ ports with 720W total power budget; delivers high-wattage power for demanding devices across all ports.
- 2x 10GB SFP+ uplink ports; enables ultra-high-speed backbone connectivity for bandwidth-intensive deployments.
- Fully managed with AW+ OS (CLI, GUI, NetCONF/RESTCONF); comprehensive control and automation for enterprise networks.
- Virtual Chassis Stack (up to 8 units); simplifies management by operating multiple switches as a single logical unit.
- Tri-authentication (MAC, web, IEEE 802.1x); multi-layer access control for maximum network security.
- Active fiber monitoring and EPSR redundancy; ensures maximum uptime and rapid fault detection across fiber links.
Downloads
Additional Information
|
Accessory Type:
|
Switch
|
|
Number of PoE Ports:
|
16 PoE Ports
|
|
Number of Ports:
|
18 Ports
|
|
PoE Standards:
|
IEEE 802.3af
IEEE 802.3at
IEEE 802.3bt
|
|
Power Budget:
|
750 Watt
|
|
Switch Type:
|
Managed
|
