Hanwha Vision SPP-K004EP Waterproof Camera Connector Kit

Hanwha Vision SPP-K004EP Waterproof Camera Connector Kit

The Hanwha Vision SPP-K004EP is a compact waterproof connector kit designed for use with Hanwha Vision TNP-A series PTZ cameras, including the TNP-A6550RW, TNP-A7430RW, and TNP-A9430RW models and their B-suffix variants. Measuring only 70mm (2.76 inches) in length and weighing just 21g (0.05 lb), it provides the IP66 and IP68-rated weatherproof connection interface required for reliable outdoor camera installations when used in conjunction with SPP-C series dedicated camera connection cables (sold separately). The connector kit ensures a secure, sealed connection point that protects against rain, dust, high-pressure water ingress, and full submersion in line with the dedicated camera connection requirements specified by Hanwha Vision.

Constructed from thermoplastic housing with copper alloy contacts in a black finish, the SPP-K004EP is rated for operation across an extreme temperature range of -50 degrees C to +60 degrees C (-58 degrees F to +140 degrees F), matching the environmental specifications of the TNP-A series cameras it serves. It is part of Hanwha Vision's SPP-C accessory ecosystem alongside the SPP-C00402EP (2m cable), SPP-C00405EP (5m cable), and SPP-C00410EP (10m cable), enabling fully weatherproofed cable assembly for demanding outdoor PTZ installations.

Key Features:

• IP66 and IP68 Rated Waterproof Connection; provides a sealed interface meeting dedicated camera connection requirements for full outdoor weatherproofing and submersion protection.
• Compatible with TNP-A6550RW, TNP-A7430RW, and TNP-A9430RW; purpose-built for Hanwha Vision TNP-A PTZ camera series ensuring plug-and-play fit and IP68 integrity.
• Compact 70mm (2.76 in) Form Factor; lightweight 21g connector enables clean, unobtrusive camera installation without adding bulk to the connection point.
• Operating Range -50 degrees C to +60 degrees C; engineered to match the extreme environmental specifications of the TNP-A camera series for year-round outdoor reliability.
• Thermoplastic and Copper Alloy Construction; durable materials ensure long service life in harsh outdoor environments.
