Hanwha Vision WRR-P-S204W-160TB Video Server & NVR with 160TB HDD Included, Windows IoT OS
The Hanwha Vision WRR-P-S204W-160TB is a 2U rackmount network video recorder designed for enterprise-level surveillance deployments requiring substantial storage capacity and reliable performance. Preloaded with Wisenet WAVE VMS and including four Wisenet WAVE Professional licenses, it ensures seamless integration with Wisenet and ONVIF-compliant IP cameras. The system offers 160TB of raw video-optimized storage across twelve front-accessible hot-swappable bays and supports RAID 0, 1, 5, and 6 configurations for data redundancy and secure long-term retention. Powered by an Intel Xeon 4410Y processor and 16GB DDR4 RAM, with dual 480GB SSDs in RAID 1 for the operating system, the server delivers up to 470 Mbps of recording throughput. Running on Windows 10 IoT Enterprise LTSC 2021, the WRR-P-S204W-160TB also features IPMI management, multiple USB ports, and dual redundant 800W power supplies, making it a robust and serviceable solution for mission-critical surveillance environments.
Key Features:
- Preloaded with Wisenet WAVE VMS; ensures quick setup and configuration.
- Includes four Wisenet WAVE Professional licenses; supports out-of-the-box camera integration.
- 160TB internal HDD storage with RAID support; enables secure, high-capacity long-term video retention.
- Dual 480GB SSDs in RAID 1; dedicated OS drives for fast and reliable system operation.
- Intel Xeon 4410Y processor with 16GB DDR4 RAM; delivers dependable performance for multi-stream video environments.
- Supports up to 470 Mbps recording throughput; ideal for enterprise surveillance workloads.
- Four RJ45 GbE network ports; provides flexible and high-speed connectivity.
- 2U rackmount chassis with 12 hot-swappable drive bays; simplifies serviceability and expansion.
- Runs on Windows 10 IoT Enterprise LTSC 2021; offers a secure, stable, and surveillance-optimized operating platform.
- Supports Wisenet and ONVIF-conformant IP cameras; ensures system-wide interoperability.
- Includes sliding rail kit with cable management and USB keyboard/mouse; streamlines deployment and use.
- 5-year limited warranty with next-business-day on-site service and keep-your-hard-drive policy; ensures maximum uptime and data protection.
Downloads
Additional Information
|
Compliance:
|
NDAA Compliant
|
|
Dimensions:
|
482 × 772.13 × 86.8 mm (18.97" × 30.39" × 3.41")
|
|
Environmental:
|
Indoor
|
|
Hard Drive Ports:
|
12 SATA Ports
|
|
Max. Storage Capacity:
|
240 TB
|
|
Pre-Installed Storage:
|
160 TB
|
|
Recorder Technology:
|
Video Server
|
