Hanwha Vision WRR-P-S204W-160TB Video Server & NVR with 160TB HDD Included, Windows IoT OS

Part Number: WRR-P-S204W-160TB
Write a Review
  • Hanwha Vision WRR-P-S204W-160TB Video Server & NVR with 160TB HDD Included, Windows IoT OS
  • Hanwha Vision WRR-P-S204W-160TB Video Server & NVR with 160TB HDD Included, Windows IoT OS
  • Hanwha Vision WRR-P-S204W-160TB Video Server & NVR with 160TB HDD Included, Windows IoT OS
$34,620.00
$25,353.03
— You save $9,266.97
Free shipping over $300 Free Shipping
Technical Support Technical Support
  • Pre-Installed Storage : 160 TB
  • Hard Drive Ports : 12 SATA Ports
  • Max. Storage Capacity : 240 TB Storage Capacity
  • Environmental : Indoor

Description

Hanwha Vision WRR-P-S204W-160TB Video Server & NVR with 160TB HDD Included, Windows IoT OS

The Hanwha Vision WRR-P-S204W-160TB is a 2U rackmount network video recorder designed for enterprise-level surveillance deployments requiring substantial storage capacity and reliable performance. Preloaded with Wisenet WAVE VMS and including four Wisenet WAVE Professional licenses, it ensures seamless integration with Wisenet and ONVIF-compliant IP cameras. The system offers 160TB of raw video-optimized storage across twelve front-accessible hot-swappable bays and supports RAID 0, 1, 5, and 6 configurations for data redundancy and secure long-term retention. Powered by an Intel Xeon 4410Y processor and 16GB DDR4 RAM, with dual 480GB SSDs in RAID 1 for the operating system, the server delivers up to 470 Mbps of recording throughput. Running on Windows 10 IoT Enterprise LTSC 2021, the WRR-P-S204W-160TB also features IPMI management, multiple USB ports, and dual redundant 800W power supplies, making it a robust and serviceable solution for mission-critical surveillance environments.

Key Features:

  • Preloaded with Wisenet WAVE VMS; ensures quick setup and configuration.
  • Includes four Wisenet WAVE Professional licenses; supports out-of-the-box camera integration.
  • 160TB internal HDD storage with RAID support; enables secure, high-capacity long-term video retention.
  • Dual 480GB SSDs in RAID 1; dedicated OS drives for fast and reliable system operation.
  • Intel Xeon 4410Y processor with 16GB DDR4 RAM; delivers dependable performance for multi-stream video environments.
  • Supports up to 470 Mbps recording throughput; ideal for enterprise surveillance workloads.
  • Four RJ45 GbE network ports; provides flexible and high-speed connectivity.
  • 2U rackmount chassis with 12 hot-swappable drive bays; simplifies serviceability and expansion.
  • Runs on Windows 10 IoT Enterprise LTSC 2021; offers a secure, stable, and surveillance-optimized operating platform.
  • Supports Wisenet and ONVIF-conformant IP cameras; ensures system-wide interoperability.
  • Includes sliding rail kit with cable management and USB keyboard/mouse; streamlines deployment and use.
  • 5-year limited warranty with next-business-day on-site service and keep-your-hard-drive policy; ensures maximum uptime and data protection.

Additional Information

Compliance:
NDAA Compliant
Dimensions:
482 × 772.13 × 86.8 mm (18.97" × 30.39" × 3.41")
Environmental:
Indoor
Hard Drive Ports:
12 SATA Ports
Max. Storage Capacity:
240 TB
Operating Humidity:
5% to 95% RH
Operating Temperature:
10 °C to 35 °C (50 °F to 95 °F)
Pre-Installed Storage:
160 TB
Recorder Technology:
Video Server
