Description
Hikvision DS-2CD2143G0-IB 2.8mm 4MP IR H.265+ Outdoor Dome IP Security Camera
The Hikvision DS-2CD2143G0-IB Outdoor IR Fixed Dome Camera provides high definition network output. It supports H.265+ video compression technology, which assures savings in bandwidth and storage.
Key Features:
- 4MP
- 1/3" CMOS
- Minimum Illumination: Color: 0.018 Lux @ (f/1.6, AGC on)
- Up to 2688 x 1520 Resolution
- 2.8 mm Fixed Lens
- H.265+/H.265/H.264+/H.264
- True WDR 120dB
- Main Stream: 30 fps (2688 × 1520, 2560 × 1440, 2304 × 1296, 1920 × 1080)
- EXIR 2.0 Range Up to 100ft (30 m)
- 12 VDC ± 25% (PoE 802.3af), maximum 7.5 W
- Built-in microSD Card slot
- Weatherproof IP67
- Vandal Proof IK10
- ONVIF
Optional Accessories:
- CPM Camera Ceiling Pendant Mount with Pendant Cap
- PC110 Pendant cap for dome camera
- CB110 Wire Intake Box for Dome Camera
Replacement of:
DS-2CD2142FWD-ISB-2.8MM
Downloads
Datasheet
Hikvision-DS-2CD2143G0-IB-Datasheet-A1
User Manual
Hikvision-DS-2CD2143G0-IB-User-Manual-A1
Quick Start Guide
Hikvision-DS-2CD2143G0-IB-Quick-Start-Guide-A1
Compatible products
Camera mounts - enclosures are essential to install security cameras. Each surface will require different type of mount and bracket combination. Please check with our sales team if you need help. You can call us at (866) 441-2288 or email us at sales@a1securitycameras.com with any design questions.
Additional Information
|
Camera Style:
|
Dome
|
|
Color:
|
Black
|
|
Compression:
|
H.265
|
|
Durability:
|
Weatherproof
|
|
Environmental:
|
Outdoor
|
|
Field of View (Horizontal):
|
103
|
|
Lens Size:
|
2.8mm
|
|
Lens Type:
|
Fixed Lens
|
|
Manufacturer Website:
|
https://us.hikvision.com/en
|
|
Night Vision Range (ft):
|
100
|
|
Product Series:
|
Hikvision Value Series
|
|
Protection Code:
|
IP67
|
|
Resolution:
|
4MP
|
|
SD Card Support:
|
SD Card Supported
|
|
Sensor Size:
|
1/3"
|
|
Sensor Type:
|
CMOS
|
|
Technology:
|
Network (IP)
|
|
Warranty:
|
3-year Manufacturer Warranty
|
|
Wide Dynamic Range (WDR):
|
True WDR 120dB
|
