Description
Hikvision DS-7616NXI-K2/16P-8TB 16-Channel PoE NVR, 8TB HDD included, Plug-and-Play, AcuSense
Key Features:
- Up to 16-ch IP camera inputs, plug & play with 16 Power-over-Ethernet (PoE) interfaces
- H.265+/H.265/H.264+/H.264 video formats
- Up to 2-ch@12 MP or 3-ch@8 MP or 6-ch@4 MP or 12-ch@1080p decoding capacity
- Up to 160 Mbps incoming bandwidth
- Adopt Hikvision Acusense technology to minimize manual effort and security costs
- All channels support Motion Detection 2.0
- 2-ch video analysis for human and vehicle recognition to reduce false alarm
- 1-ch facial recognition for video stream, or 4-ch facial recognition for face picture
- Smart search for the selected area in the video, and smart playback to improve the playback efficiency
- H.265+ compression effectively reduces the storage space by up to 75%
- Adopt stream over TLS encryption technology which provides more secure stream transmission service
- Provide independent HDMI and VGA outputs
- HDMI video output at up to 4K resolution
- Up to 2 SATA interfaces for HDD connection (up to 10 TB capacity per HDD)
- 16-ch synchronous playback
- 16 independent PoE network interfaces
- 1 self-adaptive 10/100/1000 Mbps Ethernet interface
- Hik-Connect for easy network management
Downloads
Datasheet
Hikvision-DS-7616NXI-K2-16P-Datasheet-A1
User Manual
Hikvision-DS-7616NXI-K2-16P-User-Manual-A1
Quick Start Guide
Hikvision-DS-7616NXI-K2-16P-Quick-Start-Guide-A1
Popular Search
Additional Information
|
4K Support:
|
4K Supported
|
|
Alarm Input:
|
4 Channel
|
|
Alarm Output:
|
1 Channel
|
|
Audio Capability:
|
Two-Way Audio
|
|
Audio Compression:
|
G.711ulaw
G.711alaw
G.722
G.726
AAC
|
|
Audio Input:
|
1x Channel
|
|
Audio Output:
|
1x Channel
|
|
Capacity for each disk:
|
up to 10TB
|
|
Certifications:
|
CE
FCC
IC
CB
KC
UL Listed
RoHS
REACH
WEEE
RCM
UKCA
LOA
BIS
|
|
Channel Capacity:
|
16 Channels
|
|
Compatible Integration (API):
|
ONVIF Profile S
ONVIF Profile G
SDK
ISAPI
|
|
Compression:
|
H.265
H.265 Plus
H.264
H.264 Plus
|
|
Hard Drive Ports:
|
2 SATA Ports
|
|
Languages:
|
English
Turkish
|
|
Manufacturer Website:
|
https://us.hikvision.com/en
|
|
Max Power Consumption:
|
15 Watts
|
|
Max. Incoming Bandwidth:
|
160Mbps
|
|
Max. Recording Resolution:
|
12MP (4K)
|
|
Max. Storage Capacity:
|
20 TB
|
|
Network Interface:
|
1x RJ-45 10/100/1000 Base-T
|
|
Number of PoE Ports:
|
16 PoE Ports
|
|
Outgoing Bandwidth:
|
160 Mbps
|
|
PoE Standards:
|
IEEE 802.3af
IEEE 802.3at
|
|
Pre-Installed Storage:
|
8TB HDD included
|
|
Product Series:
|
Hikvision Pro Series
|
|
Recorder Technology:
|
Network Video Recorder (NVR)
|
|
Special Technologies:
|
Hikvision AcuSense
|
|
USB Interface:
|
2x USB 2.0
|
|
Video Output:
|
1x HDMI
1x VGA
|
