LTS PTZIP772NW-X32IR 2MP Night Vision Outdoor PTZ IP Security Camera with 32x Optical Zoom - LTPTZIP772NW-X32IR
PTZIP772NW-X32IR, 2 MP 32× IR Network Speed Dome adopts 1/2.8" progressive scan CMOS chip. With the 32× optical zoom lens, the camera offers more details over expansive areas.
This series of cameras can be widely used for wide ranges of high-definition, such as the rivers, roads, railways, airports, squares, parks, scenic spots, and venues, etc. Empowered by deep learning algorithms, AI technology brings human and vehicle targets classification alarms to front- and back-end devices. The system focuses on human and vehicle targets, vastly improving alarm efficiency and effectiveness.
Key Features:
- 1/2.8" progressive scan CMOS
- High quality imaging with 2 MP resolution
- Excellent low-light performance with Ultra-Low Light technology
- Audio visual alarm: The white flashing light and audible warning can be triggered by certain events
- 32× optical zoom and 16× digital zoom provide close up views over expansive areas
- Expansive night view with up to 656ft(200 m) IR distance
- Focuses on human and vehicle targets classification based on deep learning
- Face capture: Up to 5 faces captured at the same time
Downloads
Quick Start Guide
LTS-Security-PTZIP772NW-X32IR-Quick-Start-Guide-A1
User Manual
LTS-Security-PTZIP772NW-X32IR-User-Manual-A1
Compatible products
Camera mounts - enclosures are essential to install security cameras. Each surface will require different type of mount and bracket combination. Please check with our sales team if you need help. You can call us at (866) 441-2288 or email us at sales@a1securitycameras.com with any design questions.
Additional Information
|
Alarm Input:
|
2 Channel
|
|
Alarm Output:
|
1 Channel
|
|
Alternative SKUs:
|
PTZIP772NW-X32IR
|
|
Analytics:
|
Face Capture
|
|
Aperture:
|
F1.6
|
|
Audio Capability:
|
Two-Way Audio
|
|
Audio Compression:
|
G.711ulaw
G.711alaw
G.722.1
G.726
PCM
MP2L2
MP3
AAC
|
|
Audio Input:
|
1x Channel
|
|
Audio Output:
|
1x Channel
|
|
Audio Support:
|
Built-in Speaker
|
|
Built-in Features:
|
Built-in Analytics
|
|
Camera Style:
|
PTZ
|
|
Compatible Integration (API):
|
ONVIF 19.12
ONVIF Profile G
ONVIF Profile S
ONVIF Profile T
ISAPI
SDK
ISUP
|
|
Compression:
|
H.265
H.264
H.265 Plus
H.264 Plus
MJPEG
|
|
Connection Type:
|
Wired
|
|
Day/Night:
|
Auto
Day (Color)
Night (B/W)
|
|
Detect (ft):
|
7217.8
|
|
Digital Zoom:
|
16
|
|
Dimensions:
|
220 x 363.3 mm (8.66 x 13.91 in)
|
|
Durability:
|
Weatherproof
Vandal Proof
|
|
Environmental:
|
Outdoor
|
|
Field of View (Horizontal):
|
2.6
50.8
|
|
IR LED Quantity:
|
6
|
|
Identify (ft):
|
721.8
|
|
Image Enhancements:
|
Ultra Low Light
|
|
LED Indicator:
|
|
|
Languages:
|
English
Spanish
|
|
Lens Size:
|
4.8~153mm
|
|
Lens Type:
|
Motorized (Automatic Zoom) Lens
|
|
Material:
|
ADC12
|
|
Max Power Consumption:
|
42 Watts
|
|
Max. FPS and Resolution:
|
30fps at 1080P
|
|
Minimum Illumination (B/W):
|
0 lux
|
|
Minimum Illumination (Color):
|
0.005 Lux at F1.6 AGC On
|
|
Network Interface:
|
1x RJ-45 10M/100M self-adaptive Ethernet interface
|
|
Night Vision Range (ft):
|
656
|
|
Night Vision Type:
|
Night Vision (IR)
|
|
Noise Reduction:
|
3D DNR
|
|
Observe (ft):
|
2864.2
|
|
Optical Zoom:
|
32x Optical Zoom
|
|
Power Supply:
|
24 VAC
Hi-PoE
|
|
Product Series:
|
LTS Platinum Series
|
|
Protection Code:
|
IP66
IK10
|
|
Recognize (ft):
|
1443.6
|
|
Remote Users:
|
Up to 32
|
|
Reset Button:
|
|
|
Resolution:
|
2MP
|
|
S/N Ratio:
|
>52 dB
|
|
SD Card Support:
|
SD Card Supported
|
|
Sensor Size:
|
1/2.8"
|
|
Sensor Type:
|
CMOS
|
|
Shutter Speed:
|
1-1/30000s
|
|
Surge Protection:
|
TVS 6000V
|
|
Technology:
|
Network (IP)
|
|
Warranty:
|
2-year Manufacturer Warranty
|
|
Wavelength (nm):
|
850
|
|
Wide Dynamic Range (WDR):
|
True WDR 120dB
|
