Panasonic WJ-PR204 Coaxial Lan Converter - 4-Ports Up to 45 Mbps, No setup required

Panasonic WJ-PR204 Coaxial Lan Converter

The Panasonic WJ-PR204 is an analog to IP migration system with existing coaxial cable. Connections are established by connecting the coaxial cable to the converter - easy as that!

• Two models (4-channel and 1-channel) are provided on the receiver side

Up to 4 network cameras can be connected and used on a single receiver side unit.(WJ-PR204)

• Power over Ethernet Plus (PoE+) ready

he coaxial - LAN converter is compliant with PoE+ standards (IEEE802.3at) and PoE+ cameras can be connected and used*1.

• High-speed transmission

The coaxial - LAN converter is capable of transmission speeds of 35 Mbps or over for TCP*2, and 45 Mbps or over for UDP connections*2.
(When used with RG-6/U coaxial cable, and for distances under 500 m (1,640 feet)

• No setup required

Connections can be established by simply connecting the coaxial cable to the coaxial - LAN converter.
*1 There are limitations on the combinations of the cameras to be connected, the type of power supply and transmission range to the receiver side units.
For more detail please see the operating instructions on our website
(https://i-pro.com/global/en/surveillance/training-support/support/technical-information)
*2 Transmission speed is the speed of transmission between the receiver side unit and the camera side unit.
Values may vary depending on the condition of the coaxial cable (for example, as the cable deteriorates over time), network conditions, etc.

Key Features:

• Up to 4 Network Cameras
• Power over Ethernet Ready
• High-Speed Transmission&
• 35& Mbps over TCP
• 45 Mbps over UDP
• No setup required
