Pelco CC3701H-2 480TVL Indoor Color CCTV Analog Security Camera

Pelco CC3701H-2 480TVL Indoor Color CCTV Analog Security Camera

Pelco CC3701H-2 Series is a high-resolution, high sensitivity, general purpose digital security camera with 480 TV lines. The camera features two color balance settings, automatic gain control, digital signal processing, automatic backlight compensation, and line lock. To adjust one of the camera';s many fine-tuning features, just reset the corresponding DIP switch, readily available on the left side of the camera.

Utilizing innovative technology (patent pending), the CC3701H-2 Series security camera provides an extended dynamic range over conventional high resolution cameras, without sacrificing sensitivity, color imagery, or resolution. Extended dynamic range (12X) allows the camera to provide a picture in many extreme light applications.

The CC3701H-2 Series digital color security camera is smaller than most other full-featured CCD cameras. In order to keep the camera as small as possible, Pelco engineers designed the camera components to fit within the external dimensions of the unit. Since the BNC, power, and lens connectors stay within the boundaries of the case, the compact security camera and a lens fit perfectly inside one of Pelco';s smaller enclosure(EH100, EH3508, EH2508, EH2020, EH2100, and EH2200). Pelco also has a wide selection of fixed and varifocal lenses available to meet your installation requirements.

Pelco CC3701H-2 Series digital security camera also includes Sony';s latest generation of 1/3-inch CCD imagers, accepts DC and video drive auto iris lenses, and has adjustable back focus to accommodate C or CS lenses. Back focus adjustment is easy with the lockable thumb wheel, accessible from the top or bottom of the camera.

The CC3701H-2 Series digital camera is quick and easy to install, and its distinctive design is ideal for use in confined spaces. The camera has a quick-connect power connection, BNC video connector, and a removable mount adapter for top or bottom mounting. Accessories include the PCM100 camera mount designed specifically for the CC3701H-2 Series. This adjustable mount has no exposed cabling or hardware. All cable is integrated in the unit making installation quick and easy. The PCM100 can be installed directly to a wall or ceiling, or it can be adapted to a standard 2 x 4-inch (5.08 x10.16 cm) electrical box.

Key Features:

• Sony Super HAD Technology
• EDR (Extended Dynamic Range)
• 1/3-Inch Format CCD Imager
• C/CS Lens Mount
• DC/Video Drive Auto Iris Lens Compatibility
• 24 VAC/12 VDC Power
• Line Lock With Phase Adjustment
• Automatic Gain Control (AGC)
• Backlight Compensation
• Electronic Iris
• Horizontal Resolution of 480 TV Lines
• Digital Signal Processing
• Low Profile Top/Bottom Mount
• Optional Integral Feedthrough Mount
