Pelco FTV10D1S1FC Single-Channel Fiber Transmitter with Bidirectional Data and Coaxitron Support for Long-Range Surveillance

Pelco FTV10D1S1FC Single-Channel Fiber Transmitter with Bidirectional Data and Coaxitron Support for Long-Range Surveillance

The Pelco FTV10D1S1FC is a high-performance fiber optic transmitter engineered for transmitting one composite video channel and one bidirectional data channel over a single optical fiber. Utilizing 10-bit digital encoding and laser diode technology, it ensures excellent signal integrity for long-distance surveillance applications. Its support for Pelco Coaxitron “up-the-coax” PTZ control and multiple communication protocols makes it ideal for complex installations requiring robust video and control signal transmission.

Key Features:

• 10-bit digitally encoded video for high-resolution, noise-free image quality
• One bidirectional data channel supporting RS-232, RS-422, RS-485 (2-wire/4-wire), Manchester, Bi-Phase, and Coaxitron protocols
• Coaxitron PTZ control supported up to 48 km (30 mi) over single-mode fiber
• Video transmission range up to 69 km (43 mi) using single-mode fiber
• Laser diode optical transmission delivers strong signal integrity over distance
• Exceeds EIA RS-250C specifications for short-haul transmission reliability
• Compatible with NTSC, PAL, and SECAM video formats
• Meets NEMA TS-1/TS-2 and Caltrans standards for traffic and harsh environment applications
• Modular design supports both stand-alone and rack-mounted configurations
• LED status indicators for monitoring key operating parameters
• Optical power budget of 23 dB ensures reliable performance across long fiber links
• A flexible and durable video transmission solution optimized for remote surveillance scenarios demanding long-distance video and PTZ control over a single fiber channel.
